Denon AVR-1912 Service Manual

193
Ref. No. Part No. Part Name Remarks Q'ty New
C452 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C453 nsp C,CERAMIC 0.01UF-K/50V D011103177101S
C454 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C455 nsp C,CERAMIC 0.01UF-K/50V D011103177101S
C456 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C457 nsp C,CERAMIC 0.01UF-K/50V D011103177101S
C458 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C459 nsp C,CERAMIC 10UF-K/16V D011106573200S
C460 nsp C,CERAMIC 0.01UF-K/50V D011103177101S
C461 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C462 nsp C,CERAMIC 0.01UF-K/50V D011103177101S
C463 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C464 nsp C,CERAMIC 0.01UF-K/50V D011103177101S
C465 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C466 nsp C,CERAMIC 0.01UF-K/50V D011103177101S
C467 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C468 nsp C,CERAMIC 0.01UF-K/50V D011103177101S
C469 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C470 nsp C,CERAMIC 0.01UF-K/50V D011103177101S
C471 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C472 nsp C,CERAMIC 0.01UF-K/50V D011103177101S
C473 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C474 nsp C,CERAMIC 0.01UF-K/50V D011103177101S
C475 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C476 nsp C,CERAMIC 0.01UF-K/50V D011103177101S
C477 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C478 nsp C,CERAMIC 0.01UF-K/50V D011103177101S
C479 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C480 nsp C,CERAMIC 0.01UF-K/50V D011103177101S
C481 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C482 nsp C,CERAMIC 0.01UF-K/50V D011103177101S
C483 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C484 nsp C,CERAMIC 0.01UF-K/50V D011103177101S
C485 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C486 nsp C,CERAMIC 0.01UF-K/50V D011103177101S
C487 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C488 nsp C,CERAMIC 0.01UF-K/50V D011103177101S
C489 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C490 nsp C,CERAMIC 0.01UF-K/50V D011103177101S
C491 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C492 nsp C,CERAMIC 0.01UF-K/50V D011103177101S
C493 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C494 nsp C,CERAMIC 0.01UF-K/50V D011103177101S
C495 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C496 nsp C,CERAMIC 1UF-K/10V D011105772101S
C497 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C498 nsp C,CERAMIC 10UF-K/16V D011106573200S
C499 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C500 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C501-503 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C504,505 nsp C,CERAMIC 15PF-J/50V D011150167101S
C506-509 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C510 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C511,512 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C513-515 nsp R,CHIP 0-J,1/16W C20000006M101S
C516 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C519-525 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C526 nsp C,CERAMIC 10UF-K/16V D011106573200S
C529-532 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C533 00D2544554984 C,ELECT 10UF-M/50V RA3 1912E2,1912EA D040100087380S
C534 nsp C,CERAMIC 10UF-K/16V D011106573200S
C537 nsp C,CERAMIC 10UF-K/16V D011106573200S
C539,540 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C541,542 nsp C,CERAMIC 1PF-C/50V D011010107100S
C543 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C546 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C548,549 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
f

Denon AVR-1912 Specifications

General

Impedance	47 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	90 W
HDMI in	6
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Banana connector/Binding posts
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
Ethernet LAN	Yes
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, PAL
Display	-
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD
Apple docking compatibility	iPhone, iPod
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	460 W

Weight and Dimensions

Depth	382 mm
Width	435 mm
Height	167 mm
Weight	10200 g
