Denon AVR-1912 Service Manual

194
Ref. No. Part No. Part Name Remarks Q'ty New
C550-552 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C554 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C555,556 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C557-564 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C565 nsp C,CERAMIC10PF-J/50V D011100167101S
C566,567 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C568 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C571 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C572 nsp C,CERAMIC10PF-J/50V D011100167101S
C573 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C574 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C581 nsp C,CERAMIC 0.022UF-K/25V D011223777160S
C583 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C584 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C585 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C586 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C587-593 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C594 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C595 nsp C,CERAMIC 12PF-J/50V D011120167101S
C597 nsp C,CERAMIC 12PF-J/50V D011120167101S
C598,599 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C605 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C616-619 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C620-633 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C635 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C638-641 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C642-654 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C656 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C659 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C662,663 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C664 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C665-671 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C672 nsp C,CERAMIC 0.022UF-K/25V D011223174101S
C673,674 nsp C,CERAMIC 10PF-D/50V D011100117101S
C675 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C676 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C678 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C679-683 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C684 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C685-696 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C697 nsp C,CERAMIC 0.022UF-K/25V D011223174101S
C698-701 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C702 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C703 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C706 nsp C,CERAMIC 0.01UF-K/50V D011103177101S
C708 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C710-735 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C736-785 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C786,787 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C790,791 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C792 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C796,797 nsp C,CERAMIC 9PF-D/50V D011090117101S
C799 00D9630338606 C,ELECT 10UF-MVG/16V D050100083470S
C801 nsp C,CERAMIC0.01UF-K/50V D011103777160S
C804,805 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C806-830 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C831 00D9630338606 C,ELECT 10UF-MVG/16V D050100083470S
C833 nsp C,CERAMIC0.01UF-K/50V D011103777160S
C834 nsp C,CERAMIC X7R3900PF-K/50V D011392777160S
C835 nsp C,CERAMIC 680PF-J/50V D010681167163S
C837 nsp C,CERAMIC 680PF-J/50V D010681167163S
C838 963134000450S C,ELECT 100UF-MVG/16V D050101083660S
C839 nsp C,CERAMIC 680PF-J/50V D010681167163S
C840 nsp CHIP RES. 1KJ 1/16W1005REEL C20001026M101S
C841 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C843 963134000450S C,ELECT 100UF-MVG/16V D050101083660S
C845 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S

Denon AVR-1912 Specifications

General

Impedance	47 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	90 W
HDMI in	6
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Banana connector/Binding posts
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
Ethernet LAN	Yes
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, PAL
Display	-
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD
Apple docking compatibility	iPhone, iPod
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	460 W

Weight and Dimensions

Depth	382 mm
Width	435 mm
Height	167 mm
Weight	10200 g
