84
1
Set up the
remote control unit
n Set up the zone mode
Press MAIN to switch the zone mode to the MAIN
ZONE.
MAIN lights.
Press MAIN
2
Connect the setup microphone.
Audyssey Setup
Amp Assign
Channel Select
Start
Your AV receiver can automatically measure the acoustics of
your room then optimize your speakers using the included
microphone.
Set the following items
if necessary.
When the setup microphone is
connected, the following screen is
displayed.
Set up speakers
around items indicate the settings.
First install and connect the speakers to this unit.
Before Audyssey
®
Setup measurement, the settings shown below can be made.
•Changing the amplifier assignment (Amp Assign)
The signal output from the SURROUND BACK speaker terminal of this unit can be switched to match your speaker environment (vpage84 “Set up “Amp Assign””).
•Setting the channels to be used (Channel Select)
If channels that are not to be used are set in advance, measurement for the set channels is skipped, and measuring time can be reduced. You can also change the number of surround back speakers (vpage85
“Set up “Channel Select””).
3
Set up “Amp Assign”
Use ui to select “Amp Assign”, and then press
ENTER.
Audyssey Setup/Amp Assign
Assign Mode Surround Back
ZONE2:
Assign all amps to the main zone for surround sound
speakers
Audyssey Setup
Amp Assign
Channel Select
Start
Your AV receiver can automatically measure the acoustics of
your room then optimize your speakers using the included
microphone.
Set the following items
if necessary.
4
Select “Assign Mode”, and then press ENTER.
To Next Page
