Denon AVR-2310 Service Manual

119119
AVR-2310CI/2310/890, AVC-2310
PCB PREOUT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
Q137-141 00D9630120704 TR KRA102S
J520010200210S
Q141C 00D9630044301 TR KTC2875B(MB) J5222875B0010S
Q141FL 00D9630044301 TR KTC2875B(MB) J5222875B0010S
Q141FR 00D9630044301 TR KTC2875B(MB) J5222875B0010S
Q141SBL 00D9630044301 TR KTC2875B(MB) J5222875B0010S
Q141SBR 00D9630044301 TR KTC2875B(MB) J5222875B0010S
Q141SL 00D9630044301 TR KTC2875B(MB) J5222875B0010S
Q141SR 00D9630044301 TR KTC2875B(MB) J5222875B0010S
Q141SW 00D9630044301 TR KTC2875B(MB) J5222875B0010S
Q142C 00D9630044301 TR KTC2875B(MB) J5222875B0010S
Q142FL 00D9630044301 TR KTC2875B(MB) J5222875B0010S
Q142FR 00D9630044301 TR KTC2875B(MB) J5222875B0010S
Q142SBL 00D9630044301 TR KTC2875B(MB) J5222875B0010S
Q142SBR 00D9630044301 TR KTC2875B(MB) J5222875B0010S
Q142SL 00D9630044301 TR KTC2875B(MB) J5222875B0010S
Q142SR 00D9630044301 TR KTC2875B(MB) J5222875B0010S
Q142SW 00D9630044301 TR KTC2875B(MB) J5222875B0010S
CAPACITORS GROUP
C115C 00D9639006544 C,ELECT 22UF-M/25V
D040220084050S
C115FL 00D9639006544 C,ELECT 22UF-M/25V D040220084050S
C115FR 00D9639006544 C,ELECT 22UF-M/25V D040220084050S
C115SBL 00D9639006544 C,ELECT 22UF-M/25V D040220084050S
C115SBR 00D9639006544 C,ELECT 22UF-M/25V D040220084050S
C115SL 00D9639006544 C,ELECT 22UF-M/25V D040220084050S
C115SR 00D9639006544 C,ELECT 22UF-M/25V D040220084050S
C115SW 00D9639006544 C,ELECT 22UF-M/25V D040220084050S
C141C 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C141FL 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C141FR 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C141SBL 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C141SBR 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C141SL 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C141SR 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C141SW 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C142C nsp C,CERAMIC 100PF-J/50V D010101167160S
C142FL nsp C,CERAMIC 100PF-J/50V D010101167160S
C142FR nsp C,CERAMIC 100PF-J/50V D010101167160S
C142SBL nsp C,CERAMIC 100PF-J/50V D010101167160S
C142SBR nsp C,CERAMIC 100PF-J/50V D010101167160S
C142SL nsp C,CERAMIC 100PF-J/50V D010101167160S
C142SR nsp C,CERAMIC 100PF-J/50V D010101167160S
C142SW nsp C,CERAMIC 100PF-J/50V D010101167160S
C145-148 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C172-176 00D9630244606 C,ELECT 0.1UF-M/50V (Pb Free) D040R10087080S
OTHERS PARTS GROUP
CN701 nsp CN.WAFER 8P
L101200100820S
CN702 nsp CN.WAFER 15P L101200101520S
JACK222 00D9630146209 TER,RCA RCA-405B-01 4P G602405B01000S
JACK223 963643005110S TER,RCA RCA-405B-66 G602405B6600YS
