AVR-2310CI/2310/890, AVC-2310
7. PCB SIRIUS ASSY
(1) Disconnect the board to board.
8. PCB VIDEO ASSY
(1) Disconnect the board to boards.
→
TUNER PACK
→
CHASSIS BACK
Proceeding : CABINET TOP HDMI PWB ASSY
→
→
DIGI-CNT PWB ASSY
→
PCB SIRIUS ASSY
BRACKET HDMI
→
v
Board to board
PCB DSIRIUS ASSY
→
TUNER PACK
→
CHASSIS BACK
Proceeding : CABINET TOP HDMI PWB ASSY
→
→
DIGI-CNT PWB ASSY
→
PCB SIRIUS ASSY
→
PCB VIDEO ASSY
BRACKET HDMI
→
v
Board to board
PCB VIDEO ASSY
