Denon AVR-2310 Service Manual

135
AVR-2310CI/2310/890, AVC-2310
PARTS LIST OF EXPLODED VIEW
＊ Parts for which "nsp" is indicated on this table cannot be supplied.
＊
P.W.B. ASS'Y for which "nsp" is indicated on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts table and order replacement parts.
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model
E1C : China model EA : Australia model
BK : (Black model SP : (Premium Silver model
Ref. No. Part No. Part Name Remarks Q'ty New
B-1 nsp PCB FRONT ASSY 2310CIBKE3 7025HK0818012 1*
B-1 nsp PCB FRONT ASSY 2310BKE2
7025HK0818052 1*
B-1 nsp PCB FRONT ASSY 2310SPE2
7025HK0818032 1*
B-1 nsp PCB FRONT ASSY 890BKE3
7025HK0818062 1*
B-1 nsp PCB FRONT ASSY 890BKEA
7025HK0818022 1*
B-1 nsp PCB FRONT ASSY 2310SPE1C
7025HK0818042 1*
z B1 - PCB S/W
- 1
B2 - PCB FUNCTION ENCODER
- 1
B3 - PCB FRONT
- 1
B4 - PCB H/P
- 1
B5 - PCB V.AUX
- 1
B6 - PCB FUNCTION
- 1
B7 - PCB FUNCTION CNT
- 1
B8 - PCB ENCODER
- 1
B9 - PCB ENCODER CNT
- 1
B-2 nsp PCB POWER ASSY 2310CIBKE3
7025HK0818011 1*
B-2 nsp PCB POWER ASSY 2310BKE2
7025HK0818051 1*
B-2 nsp PCB POWER ASSY 2310SPE2
7025HK0818031 1*
B-2 nsp PCB POWER ASSY 890BKE3
7025HK0818021 1*
B-2 nsp PCB POWER ASSY 890BKEA
7025HK0818021 1*
B-2 nsp PCB POWER ASSY 2310SPE1C
7025HK0818041 1*
B10 - PCB GUIDE_L
- 1
B12 - PCB GUIDE_R
- 1
B13 - PCB SUPPLY
- 1
z B14 - PCB POWER
- 1
B28 - PCB CNT3
- 1
B29 - PCB CNT2
- 1
B30 - PCB CNT1
- 1
B11 nsp PCB 2CH ASSY 2310CIBKE3
7025HK0818013 1*
B11 nsp PCB 2CH ASSY 2310BKE2
7025HK0818053 1*
B11 nsp PCB 2CH ASSY 2310SPE2
7025HK0818033 1*
B11 nsp PCB 2CH ASSY 890BKE3
7025HK0818063 1*
B11 nsp PCB 2CH ASSY 890BKEA
7025HK0818023 1*
B11 nsp PCB 2CH ASSY 2310SPE1C
7025HK0818043 1*
B-3 nsp PCB SPK ASSY 2310CIBKE3
7025HK081801B 1*
B-3 nsp PCB SPK ASSY 2310BKE2
7025HK081805B 1*
B-3 nsp PCB SPK ASSY 2310SPE2
7025HK081803B 1*
B-3 nsp PCB SPK ASSY 890BKE3
7025HK081806B 1*
B-3 nsp PCB SPK ASSY 890BKEA
7025HK081802B 1*
B-3 nsp PCB SPK ASSY 2310SPE1C
7025HK081804B 1*
B17 - PCB SPK
7028068461010 1
B18 - PCB SPK2
7028068462010 1
B19 - PCB SPK_CNT
7028068463010 1
