Denon AVR-2310 Service Manual

121121
AVR-2310CI/2310/890, AVC-2310
D530,531 00D9630341305 D,ESD IMSA-6802-01A K067680200010S
D533,534 00D9630341305 D,ESD IMSA-6802-01A K067680200010S
D708-711 00D9630341305 D,ESD IMSA-6802-01A K067680200010S
D713-720 00D9630341305 D,ESD IMSA-6802-01A K067680200010S
D801-805 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D901 963209005300S D CHIP RSX101M-30 K125101300010S
D902 963209005310S D CHIP 1SR154-400 TE25(SMD) K045154000000S
D903 00D9630355401 D,SWITCHING KDS4148U K005041480030S
ZD701 00D9630382500 D,ZENER 0.2W 5.1V UDZ K06605R14P400S
CAPACITORS GROUP
C106 nsp C,CERAMIC 4.7UF-K/6.3V
D011475571160S
C107,108 nsp C,CERAMIC COG9PF-D/50V D010090117160S
C128 nsp C,CERAMIC 0.1UF-K/16V D011104177101S
C132 nsp C,CERAMIC 0.1UF-K/16V D011104177101S
C133 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C134 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C135 nsp C,CERAMIC 0.022UF-Z/50V D011223597160S
C136 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C164-166 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C168,169 nsp C,CERAMIC 0.1UF-K/16V D011104177101S
C246-248 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C250 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C278 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C301 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C302,303 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C304 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C305 nsp C,CERAMIC 0.1UF-K/16V D011104177101S
C306 nsp C,CERAMIC 100PF-J/50V D011101167101S
C307 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C308 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C309 nsp C,CERAMIC X7R5600PF-K/50V D011562777160S
C310 nsp C,CERAMIC 390PF-K/50V D011391177101S
C311 nsp C,CERAMIC 0.1UF-K/16V D011104177101S
C312 00D9630324801 C,ELECT 10UF-MVG/25V D050100084200S
C313 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C314 nsp C,CERAMIC 0.1UF-K/16V D011104177101S
C315,316 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C317 963134005120S C,ELECT CHIP 47UF-MVG/16V D050470083200S
C318 nsp C,CERAMIC X7R1000PF-K/50V D011102777160S
C320 nsp C,CERAMIC X7R1000PF-K/50V D011102777160S
C322-324 nsp R,CHIP 0-J,1/16W C20000006M101S
C325,326 nsp C,CERAMIC COG270PF-J/50V D010271167160S
C327,328 nsp R,CHIP 0-J,1/16W C20000006M101S
C329 nsp C,CERAMIC COG390PF-J/50V D010391167160S
C330 nsp R,CHIP 0-J,1/16W C20000006M101S
C331 nsp C,CERAMIC COG390PF-J/50V D010391167160S
C332-334 nsp R,CHIP 0-J,1/16W C20000006M101S
C335,336 nsp C,CERAMIC 330PF-J/50V D010331167160S
C337-339 nsp R,CHIP 0-J,1/16W C20000006M101S
C340,341 nsp C,CERAMIC COG390PF-J/50V D010391167160S
C345 nsp C,CERAMIC COG120PF-J/50V D010121167160S
C346,347 nsp C,CERAMIC 0.1UF-K/16V D011104177101S
C348-350 nsp C,CERAMIC COG120PF-J/50V D010121167160S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-2310 Specifications

General

Equalizer	Yes
Product color	Black
Impedance	8 Ω
Frequency range	10 - 100000 Hz
Total Harmonic Distortion (THD)	0.05 %
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
S-Video inputs quantity	7
Component video (YPbPr/YCbCr) in	3
Dimensions (WxDxH)	431 x 377 x 171 mm
HDMI ports quantity	5
Connectivity technology	Wired
Headphone connectivity	3.5 mm
S-Video outputs quantity	2
Digital audio optical out	1

Weight and Dimensions

Weight	11200 g
