Denon AVR-2310 Service Manual

127127
AVR-2310CI/2310/890, AVC-2310
OTHERS PARTS GROUP
JK401-403 nsp CN.WAFER 19P
L109100190070S
JK502,503 nsp CN.WAFER 19P L109100190070S
JK701 nsp CN.WAFER 19P L109100190070S
L701-703 00D9630338800 COIL,CHIP FLC32C220K 22UH D307322200220S
L801,802 963115005140S COIL,INDUCTOR B82464Z4103M D310824641030S
L803-808 00D9630338800 COIL,CHIP FLC32C220K 22UH D307322200220S
L851,852 00D9630338800 COIL,CHIP FLC32C220K 22UH D307322200220S
TP601 00D9630342508 CN.FPC 7P L130961070010S
X101 00D3991053901 CRYSTAL CHIP FCX-03(24.5760MHz) E80524R576010S
X251 00D3991054900 CRYSTAL CHIP FCX-03(20.815MHz) E80520R815010S
X501,502 00D3991052902 CRYSTAL CHIP FCX-03(28.6363MHz) E80528R630010S
X801 00D3991117902 CRYSTAL CHIP FCX-03(30MHz) E805300000010S
X901 141810019508S CRYSTAL CHIP 16MHZ 7A16000059 E805160000010S
CW301,302 nsp CN.HOUSING 30P L121911103010S
CX046,047 nsp CN.WAFER 4P L104396040020S
CX971 00D9630342508 CN.FPC 7P L130961070010S
CX973 963644002240S CN.FPC 11P L130961110010S
CX974 00D9630342508 CN.FPC 7P L130961070010S
CY067 nsp CN.FPC 7P L130961070010S
CY111 nsp CN.FPC 11P L130961110010S
CY121 nsp CN.FPC 12P L130961120010S
CY141 nsp CN.FPC 14P L130961140010S
CY151 nsp CN.FPC 15P L130961150010S
CY193 nsp CN.FPC 19P L130961190010S
CY232 nsp CN.FPC 23P L130961230010S
FB101,102 963119004270S COIL,BEAD BLM21PG221SN1 D340201212210S
FB201,202 963119004270S COIL,BEAD BLM21PG221SN1 D340201212210S
FB401,402 963119004270S COIL,BEAD BLM21PG221SN1 D340201212210S
FB501 963119004270S COIL,BEAD BLM21PG221SN1 D340201212210S
FB502 963115003230S COIL,BEAD CBW160808U121T D340160811210S
FB601,602 963119004270S COIL,BEAD BLM21PG221SN1 D340201212210S
FB801,802 963119004270S COIL,BEAD BLM21PG221SN1 D340201212210S
FB851 963119004270S COIL,BEAD BLM21PG221SN1 D340201212210S
FB901 963115003230S COIL,BEAD CBW160808U121T D340160811210S
FB902 963119004270S COIL,BEAD BLM21PG221SN1 D340201212210S
FB903 963115003230S COIL,BEAD CBW160808U121T D340160811210S
RA801-806 nsp R,NETWORK 0-J 1/16W SMD(1005) C180000040500S
RA851-858 nsp R,NETWORK 0-J 1/16W SMD(1005) C180000040500S
RA859-864 nsp R,NETWORK 150*4 1/16W SMD(1005) C180151040500S
TR122 00D9630120801 TR KRC102S J522010200210S
TR253,254 00D9630120801 TR KRC102S J522010200210S
TR301-303 00D9630120801 TR KRC102S J522010200210S
TR304,305 00D2750100902 TR 2SK771 J543771000010S
TR306 00D9630121402 TR 2SA KRA104S R1 J520010400210S
TR307 00D9600285006 TR KRC104S J522104S00210S
TR401,403 00D9630120801 TR KRC102S J522010200210S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-2310 Specifications

General

Equalizer	Yes
Product color	Black
Impedance	8 Ω
Frequency range	10 - 100000 Hz
Total Harmonic Distortion (THD)	0.05 %
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
S-Video inputs quantity	7
Component video (YPbPr/YCbCr) in	3
Dimensions (WxDxH)	431 x 377 x 171 mm
HDMI ports quantity	5
Connectivity technology	Wired
Headphone connectivity	3.5 mm
S-Video outputs quantity	2
Digital audio optical out	1

Weight and Dimensions

Weight	11200 g
