Denon AVR-2310 Service Manual

129129
AVR-2310CI/2310/890, AVC-2310
PCB SPK ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
Q542-546 00D9630121606 TR KRC107S
J522107S00210S
D542-546 00D9630355401 D,SWITCHING KDS4148U K005041480030S
RESISTORS GROUP
R501C 00D9639006256 R,FIXED 1WJ-10
N113135610020S
R501FL 00D9639006256 R,FIXED 1WJ-10 N113135610020S
R501FR 00D9639006256 R,FIXED 1WJ-10 N113135610020S
R501SBL 00D9639006256 R,FIXED 1WJ-10 N113135610020S
R501SBR 00D9639006256 R,FIXED 1WJ-10 N113135610020S
R501SL 00D9639006256 R,FIXED 1WJ-10 N113135610020S
R501SR 00D9639006256 R,FIXED 1WJ-10 N113135610020S
CAPACITORS GROUP
C501C nsp C,FILM 0.1UF-J/50V
D020104167050S
C501FL nsp C,FILM 0.1UF-J/50V D020104167050S
C501FR nsp C,FILM 0.1UF-J/50V D020104167050S
C501SBL nsp C,FILM 0.1UF-J/50V D020104167050S
C501SBR nsp C,FILM 0.1UF-J/50V D020104167050S
C501SL nsp C,FILM 0.1UF-J/50V D020104167050S
C501SR nsp C,FILM 0.1UF-J/50V D020104167050S
C541 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C541FL nsp C,FILM 0.015UF-J/100V D02015306C060S
C542 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C542FR nsp C,FILM 0.015UF-J/100V D02015306C060S
C543 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C543FL nsp C,FILM 0.015UF-J/100V D02015306C060S
C544 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C544FR nsp C,FILM 0.015UF-J/100V D02015306C060S
C545 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C545C nsp C,FILM 0.015UF-J/100V D02015306C060S
C546 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C546SL nsp C,FILM 0.015UF-J/100V D02015306C060S
C547 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C547SR nsp C,FILM 0.015UF-J/100V D02015306C060S
C548 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C548SBL nsp C,FILM 0.015UF-J/100V D02015306C060S
C549 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C549SBR nsp C,FILM 0.015UF-J/100V D02015306C060S
C550 00D9609010735 C,ELECT 100UF-M/16V D040101083060S
OTHERS PARTS GROUP
CN101B nsp CN.WAFER 4P
L102526700400S
CN102 nsp CN,WIRE 4P L000311040020S
CN105 nsp CN.WAFER 16P L101100031610S
CP101A nsp CN.WAFER 6P L102526700600S
CP103 nsp CN.WAFER 8P L101200100810S
CP104,105 nsp CN.WAFER 16P L101100041610S
CP106 nsp CN.WAFER 16P L101100031610S

Denon AVR-2310 Specifications

General

Equalizer	Yes
Product color	Black
Impedance	8 Ω
Frequency range	10 - 100000 Hz
Total Harmonic Distortion (THD)	0.05 %
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
S-Video inputs quantity	7
Component video (YPbPr/YCbCr) in	3
Dimensions (WxDxH)	431 x 377 x 171 mm
HDMI ports quantity	5
Connectivity technology	Wired
Headphone connectivity	3.5 mm
S-Video outputs quantity	2
Digital audio optical out	1

Weight and Dimensions

Weight	11200 g
