Denon AVR-2310 Service Manual

49
AVR-2310CI/2310/890, AVC-2310
21 P77/(CLK5) SI CODECO I - Lv - - Z O/L O/L Z CODEC(ADAU1328) control
22 P76/(TXD5) TMS/M/D O C - - Eu Z O/L - O/L FPGA firmware update control (JTAG)
23 P75 TDI O C - - - Z O/L O/L Z FPGA firmware update control (JTAG)
24 P74 MTCK O C - - - Z O/L O/L Z FPGA firmware update control (JTAG)
25 P73/(CTS2) ANALOG VIDEO
POWER
O C - - - Z O/L O/L Z Analog video components power control
26 P72/(CLK2) DIGITAL(D/A)
POWER
O C - - - Z Z - Z Digital audio components power control
27 P71/RXD2/
SCLMM
HSCL(400k) I/O N - - Eu Z O/L O/L O/L Interface between IP CONV(ABT2010)/
HDMI_RECEIVER(ADV7840)/HDMI
TRANSMITTER1 (ADV7510)
28 P70/TXD2/
SDAMM
HSDA(400k) I/O N - - Eu Z O/L O/L O/L Interface between IP CONV(ABT2010)/
HDMI_RECEIVER(ADV7840)/HDMI
TRANSMITTER1 (ADV7510)
29 P67/TXD1 TXD O C - - Eu Z - - Z Interface between Sub CPU and external i/o port
30 P66/RXD1 RXD I - Lv - Eu Z - - Z Interface between Sub CPU and external i/o port
31 P65/(CLK1) SW SUM O C - - Ed Z - O/L Z Subwoofer signal control
32 P64/(CTS1) CFSEL0 O C - - Ed Z - O/L Z COMPONENT HD OUT filter control
33 P63/TXD0 SOMI O C - - - Z - - Z Interface between Main CPU and Sub CPU
34 P62/RXD0 SIMO I - - - Ed Z - - Z Interface between Main CPU and Sub CPU
35 P61/CLK0 CLK SIMO I - - - Ed Z - - Z Interface between Main CPU and Sub CPU
36 P60/(CTS0) REQ SOMI O C - - Ed Z - - Z Interface between Main CPU and Sub CPU
37 P57 1TMDS SW RST O C - - - Z O/H - Z HDMI switcher (ADV3002) reset signal out put
38 P56 HPD2 O C - - - Z O/L - Z HDMI control (hot plug detect)
39 P55/EPM EPM O C - - Ed Z - - Z Firmware update control
40 P54 CEC_OUT O C - - - Z O/L - Z CEC-D signal output terminal
41 P53 MONI DIS O C - - Z O/L O/L Z COMPONENT MONITOR OUT output control
terminal
42 P52 DVR INH O C - - - Z O/L O/L Z Video recout (DVR) control
43 P51 VCR INH O C - - - Z O/L O/L Z Video recout (VCR) control
44 P50/CE CE O C - - Eu Z O/L - Z Firmware update control
45 P47/(TXD7)/
SDA7
VSDA I/O C - - Eu Z O/L - O/L Video encoder (ADV7340) /
Component Sel(NJW1321FP1) control (I2C)
46 P46/(RXD7)/
SCL7
VSCL I/O C - - Eu Z O/L - O/L Video encoder (ADV7340) /
Component Sel(NJW1321FP1) control (I2C)
47 P45/(CLK7) HPD1 O C - - Ed Z O/L - Z HDMI control (hot plug detect)
48 P44 NC O C - - - Z Z - Z
49 P43 HDMI A.SEL O C - - Ed Z O/L O/L Z HDMI audio select
50 P42 NC O C - - Ed Z O/L O/L Z
51 P41 CEC PWR O C - - Ed Z O/L O/H Z CEC components power control
52 P40 Z1 SMONIA O C - - Z O/L O/L Z SMONITOR select
53 P37 HDMIR_RST O C - - Eu Z O/H - Z HDMI receiver (ADV7840) reset signal output
54 P36 1TX RST O C - - Eu Z O/H - Z HDMI transmitter (ADV7510) reset signal outpu
55 P35 Z1 SMONIB O C - - Ed Z O/L O/L Z Main zone SMONITOR select
56 P34 Z1 SSIGDET I - Lv - Eu Z - - Z Video(S) signal detect
57 P33 NC O C - - - Z Z - Z
58 P32 SO CODECI O C - - - Z O/L O/L Z CODEC (ADAU1328) control
59 P31 CLK CODEC O C - - - Z O/L O/L Z CODEC (ADAU1328) control
60 VCC VCC - - - - - - - - - +3.3V
61 P30 CE CODEC O C - - - Z O/L O/L Z CODEC (ADAU1328) control
62 VSS VSS - - - - - - - - - GND
63 P27 CODEC RST O C - - - Z O/H O/L Z CODEC (ADAU1328) control
64 P26 DIG VIDEO
POWER
O C - - - Z O/L MODE1=O/H
MODE2=O/L
Digital video components power control
65 P25/INT7 OSD CPU
BUSYSI
I - Lv - - Z - - Z Interface between Sub CPU and D.OSD CPU
66 P24/INT6 1TX INT I - Lv - . Z - - Z HDMI output signal detect
67 P23 NC O C - - - Z Z - Z
68 P22 VEXP STB O C - - - Z O/L O/L Z Extended i/o components (BU4094BCFV) control
69 P21 VEXP OE O C - - Ed Z O/L O/L Z Extended i/o components (BU4094BCFV) control
70 P20 VEXP CLK O C - - - Z O/L O/L Z Extended i/o components (BU4094BCFV) control
71 P17/INT5 ADVINT1 I -
E
↓ &L
- - Z - - Z HDMI receiver(ADV7840) control
72 P16/INT4 ADVINT2 I -
E
↓ &L
- - Z - - Z HDMI receiver(ADV7840) control
73 P15/INT3 ADVINT3 I -
E
↓ &L
- - Z - - Z HDMI receiver(ADV7840) control
74 P14 NC O C - - Eu Z - - Z
75 P13/TXD6 DSP MOSI O C - - Eu Z O/L O/L Z DSP (ADSP-21367-333) control
Pin
No.
PIN PIN NAME I/O Type Det
Op
(in)
Op(ex) Res
PURE
D
CEC STBY
P. O F
F
Function
