Denon AVR-2310 Service Manual

9797
AVR-2310CI/2310/890, AVC-2310
Q180 00D2730471907 TR 2SC KTC3206Y J5023206Y0050S
Q181-185 00D2710318909 TR 2SA 2N5401S J520254010010S
Q221L 00D9630044301 TR KTC2875B(MB) J5222875B0010S
Q221R 00D9630044301 TR KTC2875B(MB) J5222875B0010S
Q227L 00D9630044301 TR KTC2875B(MB) J5222875B0010S
Q227R 00D9630044301 TR KTC2875B(MB) J5222875B0010S
Q231 00D9630121402 TR 2SA KRA104S R1 J520010400210S
Q541 00D9630121208 TR KRC107M J6020107M0010S
D101C 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D101FL 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D101FR 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D101SL 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D101SR 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D102C 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D102FL 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D102FR 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D102SL 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D102SR 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D105C 00D9630020309 D,SWITCHING 1SS133T K000013300520S
D105FL 00D9630020309 D,SWITCHING 1SS133T K000013300520S
D105FR 00D9630020309 D,SWITCHING 1SS133T K000013300520S
D105SL 00D9630020309 D,SWITCHING 1SS133T K000013300520S
D105SR 00D9630020309 D,SWITCHING 1SS133T K000013300520S
D106 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D106C 00D9630020309 D,SWITCHING 1SS133T K000013300520S
D106FL 00D9630020309 D,SWITCHING 1SS133T K000013300520S
D106FR 00D9630020309 D,SWITCHING 1SS133T K000013300520S
D106SL 00D9630020309 D,SWITCHING 1SS133T K000013300520S
D106SR 00D9630020309 D,SWITCHING 1SS133T K000013300520S
D107 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D114,115 00D9600197107 D,RECTIFIER BRIDGE KBPC604 K047604000020S
D139 00D9630020309 D,SWITCHING 1SS133T K000013300520S
D140,141 00D9630328409 D,SWITCHING 1N4007 K000400700010S
D160-174 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D175,176 00D9630020309 D,SWITCHING 1SS133T K000013300520S
D231 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D541 00D9630355401 D,SWITCHING KDS4148U K005041480030S
ZD101 00D9600128105 D,ZENER MTZJ9.1B K06009R144520S
ZD101C 00D9630367008 D,ZENER 0.2W 3.3V UDZ K06603R34P400S
ZD101FL 00D9630367008 D,ZENER 0.2W 3.3V UDZ K06603R34P400S
ZD101FR 00D9630367008 D,ZENER 0.2W 3.3V UDZ K06603R34P400S
ZD101SL 00D9630367008 D,ZENER 0.2W 3.3V UDZ K06603R34P400S
ZD101SR 00D9630367008 D,ZENER 0.2W 3.3V UDZ K06603R34P400S
ZD102C 00D9630382209 D,ZENER 0.2W 3.0V UDZ K06603R04P400S
ZD102FL 00D9630382209 D,ZENER 0.2W 3.0V UDZ K06603R04P400S
ZD102FR 00D9630382209 D,ZENER 0.2W 3.0V UDZ K06603R04P400S
ZD102SL 00D9630382209 D,ZENER 0.2W 3.0V UDZ K06603R04P400S
ZD102SR 00D9630382209 D,ZENER 0.2W 3.0V UDZ K06603R04P400S
ZD105 00D9600095500 D,ZENER MTZJ5.1B K06005R144520S
ZD106 00D9630219903 D,ZENER MTZJ16B 2310 K06016R044520S
ZD231 00D9600095704 D,ZENER MTZJ6.2B-0.5W/5MA-52MM K06006R244520S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-2310 Specifications

General

Equalizer	Yes
Product color	Black
Impedance	8 Ω
Frequency range	10 - 100000 Hz
Total Harmonic Distortion (THD)	0.05 %
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
S-Video inputs quantity	7
Component video (YPbPr/YCbCr) in	3
Dimensions (WxDxH)	431 x 377 x 171 mm
HDMI ports quantity	5
Connectivity technology	Wired
Headphone connectivity	3.5 mm
S-Video outputs quantity	2
Digital audio optical out	1

Weight and Dimensions

Weight	11200 g
