Denon AVR-2807 Service Manual

40
AVR-2807
BH7868FS (DI : IC608)
TC74VHCU04F (MA : IC902,903)
CXA1511M (FR : IC701)
+
Vcc1
S1
S2
C IN
MUTE1
CV IN
Y IN
BIAS
Py/G IN
GND
Pb/B IN
MUTE2
Pr/R IN
Vcc2
SEL(CV/MIX)
SEL(BIAS/CLAMP)
COUT
S-DC OUT
CVOUT
CVOUT SAG
GND
YOUT
GND
Py/G OUT
Pb/B OUT
GND
Pb/B OUT SAG
GND
Pr/R OUT
Pr/R OUT SAG
YOUT SAG
Py/G OUT SAG
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
75Ω
75Ω
75Ω
75Ω
75Ω
75Ω
6dB
6dB
6dB
6dB
6dB
6dB
Bias
Bias
Bias
Bias
Bias
Clamp
Clamp
Clamp
13.5MHz
LPF
13.5MHz
LPF
13.5MHz
LPF
6.75MHz
LPF
6.75MHz
LPF
6.75MHz
LPF
S-DC OUT
S1/S2
MUTE2
MUTE1
L
H
L
H

Denon AVR-2807 Specifications

General

Number of Channels	7.1
HDMI Inputs	2
HDMI Outputs	1
Component Video Inputs	3
Component Video Outputs	1
Dolby Digital	Yes
DTS	Yes
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Total Harmonic Distortion	0.05%
Input Sensitivity	200 mV
Signal-to-Noise Ratio	100 dB
Speaker Impedance	6-16 ohms
Tuner Type	AM/FM
Power Output	110W per channel
Digital Audio Inputs	2 coaxial
Auto Setup	Audyssey MultEQ
Multi-room	Yes
Width	434 mm
Height	171 mm
Dimensions	434 x 171 x 414 mm
