Denon AVR-3312 - Page 111

111
+29dB
Config2 DOLBY LIMIT LEVEL 1.41Vrms(ALLch-3dBFS)
FULL SCALE LEVEL=2Vrms
PLD
DSP
-2+6.5+3=7.5dB
-2+3=1dB
-2+3+6=7dB
+20dB
+10dB
0dB
-20dB
-30dB
-40dB
-10dB
+20dB
+10dB
0dB
-20dB
-30dB
-40dB
-10dB
LEVEL DIAGRAM
SURR.BACK ch
0dBFS
-10dBFS
-20dBFS
-30dBFS
-40dBFS
-29dBFS(A/D IN)
200mV
+30dB
SP OUT
4.24Vrms/8Ω
-26dBFS(DIG.IN)
DD EX Config1
SP OUT(D/A OUT)
3.00Vrms/8Ω
-32.5dBFS(DIG.IN)
DD EX Config2
INPUT : -23dBFS(DIG.IN) D.D
INPUT : 200mV(A/D IN)
Mch STEREO
＋
＋
SPEAKER
OUT
R2A15220FP
GAIN
ADJ.
AK4358VQ
D/A
－
－
＋
AZ4580 MAX.OUTPUT 7.78Vrms
R2A15220FP MAX.OUTPUT 3.8Vrms
AK4358VQ
DIFF.OUT
0dBFS=5Vpp
=1.77Vrms
+1.07dB
200mVrms
PREOUT
150mVrms
