DDC_CLK/DDC_DATA/TMDS : Check items (17)/(19)/(24)/(32)
Timing waveform illustration from the start of CEC3.3V to when reset is released
:
Check items (22)
0.9V
2.48V
TMDS Waveform
DDC_CLK
DDC_DATA
CEC3.3V
3002_RESET
338ms
Controlled waveform(I2C), when power is turned on : Check items (23)
HDMI_SCL
HDMI_SDA
POWER ON
