Denon AVR-3312

10
2. HEAT SINK ASSY
(1) Remove the screws.
(2) Cut the wire clamp band, then remove the screws. Disconnect the connector wires.
CABINET TOP
HEAT SINK ASSY
→
Proceeding :
View from the bottom
Shooting direction: D
Shooting direction: C
cut
cut
CN602
