Denon AVR-3312 Service Manual

217
PCB SMPS ASSY
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
z
IC901 231010091708S I.C , OFF-LINE POWER SWITCH CVITOP258MG
z
IC902 963239010480S I.C , PHOTOCOUPLER CVIPC123Y22FZ0F
IC903 212050010508S I.C , SHUNT REGULATOR(TO-92) CVIKIA2431AP
Q9001-9003 00MHT30001000 TR KTC3199Y HVTKTC3199YT
D9001-9006 00D9630328409 DIODE , RECTIFIER, AXIAL CVD1N4007ST
D9008,9009 00D9630328409 DIODE , RECTIFIER, AXIAL CVD1N4007ST
D9010 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D9012 943209500030S DIODE , LOW FORWARD SCHOTTKY
RECTIFIER
CVDSRL3060P
D9013 963209010430S DIODE , RECTIFIER CVDAP01CT
CAPACITORS GROUP
z
C9001-9003 963132011940S CAP, CERAMIC(X1/Y2,0.01uF,AC250V) CCKDKY103MFM
C9004 943134501590S CAP , ELECT(200V/100uF)105, 16X20 E3 CCET200NHA101ES *
C9004 963134010200S CAP, ELECT(400V/100uF)105,18X31.5 E2,E1C CCET400NHA101ES *
C9006-9008 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C9009 00D9430175108 CAP , ELECT(50V/10uF) CCEA1HNXA100TS
C9010 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C9012 963132010120S CAP, CERAMIC(DC1KV/1000pF) CCKDDEH102KCM
C9016 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C9017 00MOA47602520 CAP, ELECT(25V/47uF) CCEA1ENXA470TS
C9018 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C9019 nsp CAP, CHIP(1608,6.3V/4.7uF) CCUS0J475KC
C9020-9022 963134010220S CAP , ELECT(6.3V/5600uF) CCEA0JNXA562ES
C9024 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
z
C9028 963132011930S CAP, CERAMIC(X1/Y1,2200P,AC250V) CCKDKX222MEM
C9029 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
RESISTORS GROUP
R9021 nsp RES, CHIP(1608/1%/22Kohm) CRJ10DF2202T
R9024 nsp RES, CHIP(1608/1%/6.8Kohm) CRJ10DF6801T
z
R9031-9034 943121500030S RES, CHIP(2012/5%/2.2Mohm) CRJ18AJ225T
OTHERS PARTS GROUP
BK901 nsp PCB BRACKET CMD1A188
BK903 nsp
BRACKET , PCB CMD1A629
BN903 nsp
WIRE ASS'Y LOCKING
(5P,2.5MM,400MM,UL1569#22,105)
CWB7D0054003D001
CN902 nsp WAFER 2PIN CJP02GA89ZY
z
CX901 943139500020S
CAP , POLYPROPYLENE FILM
(0.1uF/275VAC)
CCQF2E104KZE-T
z
CY901,902 963134011730S CAP, CERAMIC(X1/Y1,470P,AC250V) CCKDKX471KBM
F9001 nsp FUSE HOLDER KJCFC5S
z
F9001 963652010510S FUSE(S506 Series, 250V,2A) CBA2C2000TLEC
z
F9002 nsp FUSE HOLDER KJCFC5S
z
F9002 652010025056S FUSE(S506 Series, 250V,6.3A) CBA2C6300TLEC
z
F9301-9305 963652010910S FUSE(S506 Series, 250V,3.15A) CBA2C3150TLEC
z
JK901 963641011240S RECEPTACLE, (10A/AC250V) CJJ8A015ZM
z
LF902 963111010230S LINE FILTER, 27uH CLZ9Z126Z
z
RY901 963682010370S RELAY, POWER(DC5V, 1C1P) CSL1C006ZE
z
T9001 963102010240S TRANS, SWITCHING(ST-4430A) CLT9Z067ZE

Denon AVR-3312 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Speaker selector	A+B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.8 %
Power output per channel (1KHz@8 Ohm)	165 W
Power output per channel (20-20KHz@8 Ohm)	125 W
HDMI in	7
Audio (L/R) in	8
Composite video in	5
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	2
Composite video out	3
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Internet radio services supported	Last.fm, Napster
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Display	VFL
HDMI version	1.4a
Product color	Black
Audio decoders	Dolby Pro Logic IIz, Dolby TrueHD, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	iPad, iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	670 W
Card reader integrated	-
Cables included	AC

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	11800 g
