Denon AVR-3312 Service Manual

216
Ref. No. Part No. Part Name Remarks Q'ty New
R5112 nsp CHIP RES1%75OHM CRJ10DF75R0T
R5115 nsp CHIP RES1%75OHM CRJ10DF75R0T
R5118 nsp CHIP RES1%75OHM CRJ10DF75R0T
R5120 nsp CHIP RES1%75OHM CRJ10DF75R0T
R5122 nsp CHIP RES1%75OHM CRJ10DF75R0T
R5142,5143 nsp RES, CHIP(1608/1%/510ohm) CRJ10DF5100T
R5149,5150 nsp RES, CHIP(1608/1%/560ohm) CRJ10DF5600T
R5160,5161 nsp CHIP RES1%75OHM CRJ10DF75R0T
R5232-5234 nsp CHIP RES1%75OHM CRJ10DF75R0T
R5248,5249 nsp CHIP RES1%75OHM CRJ10DF75R0T
R5269-5271 nsp CHIP RES1%75OHM CRJ10DF75R0T
R5301 nsp CHIP RES1%75OHM CRJ10DF75R0T
OTHERS PARTS GROUP
BN51A nsp WIRE ASS'Y
(1P,100MM,BLK,UL1007#24,CKM-T)
CWE4202100AT
BN53A nsp WIRE ASS'Y
(1P,100MM,BLK,UL1007#24,CKM-T)
CWE4202100AT
CN51B nsp PIN SOCKET (15P,1.25mm,ANGLE,
B-TO-B)
CJP15HJ282Z
CN52B nsp PIN SOCKET (17P,1.25mm,ANGLE,
B-TO-B) P
CJP17HJ282Z
CN53B nsp PIN SOCKET (13P,1.25mm,ANGLE,
B-TO-B)
CJP13HJ282Z
CN931 nsp LOCK-WAFER/ANGLE/2MM PITCH/5PIN CJP05GJ288ZY
JK551 943643101070S JACK, 4P YL (RCA-405B-31) CJJ4P075Z *
JK553 943643101080S JACK, S-VIDEO (DIN-409A X 2) CJJ9N001Z *
JK554 943643101090S JACK, 4P YL (RCA-405B-4-31) CJJ4P078Z *
JK556-558 943643101100S JACK, 3P (RCA-303D-00-08) CJJ4S050Z *

Denon AVR-3312 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Speaker selector	A+B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.8 %
Power output per channel (1KHz@8 Ohm)	165 W
Power output per channel (20-20KHz@8 Ohm)	125 W
HDMI in	7
Audio (L/R) in	8
Composite video in	5
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	2
Composite video out	3
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Internet radio services supported	Last.fm, Napster
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Display	VFL
HDMI version	1.4a
Product color	Black
Audio decoders	Dolby Pro Logic IIz, Dolby TrueHD, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	iPad, iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	670 W
Card reader integrated	-
Cables included	AC

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	11800 g
