Denon AVR-3312 Service Manual

202
Ref. No. Part No. Part Name Remarks Q'ty New
C6523 943134501550S CAP , ELECT(50V/10uF)-S
CCEA1HKS100T *
C6601 943134501550S CAP , ELECT(50V/10uF)-S
CCEA1HKS100T *
C6603,6604 nsp CHIP CAP 330PF 50V J
CCUS1H331JA
C6623,6624 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C6691 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C6693 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C6694 943134501540S CAP , ELECT(50V/1uF)-S CCEA1HKS1R0T *
C6702 nsp CHIP CAP 0.1UF 50V K
CCUS1H104KC
C6712 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C6719 00D9430062101 ELECT CAP 100UF 16V CCEA1CH101T
C6720 nsp CAP, CHIP(1608, 50V/82pF) CCUS1H820JA
C6726 nsp CAP, CHIP(1608, 50V/0.047uF) CCUS1H473KC
C6731,6732 943134010530S ELECT CAP 1UF 50V C CCEA1HH1R0T
C6733 943134501540S CAP , ELECT(50V/1uF)-S CCEA1HKS1R0T *
C6735 nsp CHIP CAP 100PF 50V J
CCUS1H101JA
C6753 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C6755 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C6802 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C6803 00D9430173003 CAP , ELECT(10V/220uF)-S CCEA1AKS221T
C6812 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
OTHERS PARTS GROUP
BK601,602 nsp FIP BRACKET
CMD1A572
BK603 nsp PCB BRACKET CMD1A569
BK611 nsp EARTH AUX CMC1A421
BK612 nsp EARTH , USB CMC1A420
BN601 nsp
WIRE ASS'Y LOCKING
(7P,2.0MM,050MM,UL1007#24)
CWB1C007050HC
BN604 nsp
WIRE ASS'Y LOCKING
(9P,2.0MM,050MM,UL1007#24)
CWB1C009050HC
BN605A nsp
WIRE ASS'Y B'D to B'D
(5P,2.0MM,050MM,UL1007#24)
CWB1C005050CC
BN608 nsp
WIRE ASS'Y (5P,2.0MM,550MM,UL2725#
24/#28,1P+2C)USB
CWB8A005550LC
CN404 nsp LOCK-WAFER/ANGLE/2MM PITCH/9PIN CJP09GJ288ZY
CN601 nsp LOCK-WAFER/ANGLE/2MM PITCH/7PIN CJP07GJ288ZY
CN602 nsp WAFER,YMAW025(2.5mm,ANGLE) CJP07GB03ZY
CN69A nsp WAFER, FFC, 40P, 1mm, ANGLE(DIP) CJP40GB284ZN
z
F6001 943652000620S FUSE(0.1A 372SERIES/TR5) CBA2D0100A3EYT
FL601 943172100110S V.F.D (19-ST-02GINAK) CFL19ST02GINAK *
JK605 943643010130S JACK PHONES(6.35mm)
CJJ2E020Z
JK606 90M-YT004310R JACK BOARD(3P) CJJ4S041Z
JK607 943643100160S JACK, MONO, 3.5mm CJJ1D001Z
JK608 943643100150S JACK , USB STRAIGHT(BLACK) CJJ9X006Z
JW602,603 nsp WIRE ASS'Y (1P, 80MM,BLK,#22) CWE5202080A
L6001 nsp FERRITE CHIP BEAD(2012/220ohm) CLZBLM21PG221SN1
L6501 nsp RES,CHIP(0OHM,5%,1608) CRJ10DJ0R0T
L6601 nsp RES,CHIP(0OHM,5%,1608) CRJ10DJ0R0T
LD601 943176010090S LED BLBJEGJ204L CVDBLBJEGJ204L
LD602 963262010460S LED SIR-341ST3F CVDSIR341ST3FT0
RC601 943262010290S REMOCON SENSOR CRVKSM603TH5B
SW601-605 90M-SP001400R TACT SW EVQ22505R CST1A023ZT
SW611-616 90M-SP001400R TACT SW EVQ22505R CST1A023ZT
SW621-626 90M-SP001400R TACT SW EVQ22505R CST1A023ZT
SW631 90M-SP001400R TACT SW EVQ22505R CST1A023ZT
VR601 943671010330S ENCODER VR CSR2A055Z
VR604 943671010330S ENCODER VR CSR2A055Z

Denon AVR-3312 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Speaker selector	A+B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.8 %
Power output per channel (1KHz@8 Ohm)	165 W
Power output per channel (20-20KHz@8 Ohm)	125 W
HDMI in	7
Audio (L/R) in	8
Composite video in	5
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	2
Composite video out	3
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Internet radio services supported	Last.fm, Napster
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Display	VFL
HDMI version	1.4a
Product color	Black
Audio decoders	Dolby Pro Logic IIz, Dolby TrueHD, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	iPad, iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	670 W
Card reader integrated	-
Cables included	AC

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	11800 g
