Denon AVR-3312 Service Manual

212
Ref. No. Part No. Part Name Remarks Q'ty New
CN941 nsp
LOCK-WAFER/STRAIGHT/2.5MM PITCH/3PIN CJP03GI289ZY
CN97A nsp PIN HEADER (15P,1.25mm,STRAIGHT,B-TO-B) CJP15GI281Z
CN98A,99 nsp PIN HEADER (11P,1.25mm,STRAIGHT,B-TO-B) CJP11GI281Z
F9301-9305 nsp FUSE HOLDER KJCFC5S
GND71 nsp EARTH PALTE HJT1A025
JK681 643010076005S JACK, 4P(W/R,W/R),SEPA-GND, SILVER CJJ4P048Z
JK682 643010079004S JACK, 4P(W/R,W/B),SEPA-GND, SILVER CJJ4P077Z
JK683 643010076005S JACK, 4P(W/R,W/R),SEPA-GND, SILVER CJJ4P048Z
JK684 943643010160S JACK NOSPCC1PBLACK CJJ4M046U
JK689 943643010150S JACK NOSPCC2PW/R CJJ4N034U
JK781 943646010240S JACK NOSPCC6PRRR/BBB CJJ5R008U
JK782 943643101050S JACK, SPK 8P (JB-801A-CU-02) CJJ5Q007U *
JK783 943646010250S JACK NOSPCC4PRR/BB
CJJ5P011U
JK784,785 943643101060S JACK, SP 2P (JB-206-01) CJJ5N018Z *
JW703A nsp
WIRE ASS'Y
(1P,200MM,BLK,UL1015#20,CKM-T)
CWE7102200TT
JW704A nsp
WIRE ASS'Y
(1P,220MM,BLK,UL1015#20,CKM-T)
CWE7102220TT
JW705A nsp
WIRE ASS'Y
(1P,220MM,RED,UL1015#20,CKM-T)
CWE7112220TT
L6752 943115010270S MPX COIL(FM19KHzFILTER) E2 CLM4B001Z
L6922 943115010270S MPX COIL(FM19KHzFILTER) E2 CLM4B001Z
L7801 943115010260S SPEAKER COIL (0.5UH) CLEY0R5KAK
L7811 943115010260S SPEAKER COIL (0.5UH) CLEY0R5KAK
L7821 943115010260S SPEAKER COIL (0.5UH) CLEY0R5KAK
L7831 943115010260S SPEAKER COIL (0.5UH) CLEY0R5KAK
L7841 943115010260S SPEAKER COIL (0.5UH) CLEY0R5KAK
L7851 943115010260S SPEAKER COIL (0.5UH) CLEY0R5KAK
L7861 943115010260S SPEAKER COIL (0.5UH) CLEY0R5KAK
RY781-784 682010023006S RELAY 12V 2C1P CSL3A021ZU
RY786,787 682010023006S RELAY 12V 2C1P CSL3A021ZU
RY788 943682000810S RELAY 12V 2C2P CSL4A016ZU
TM601 183010013007S MODULE , TUNER E2 CNVKSTMT104MV1-2
TM601 183010014000S MODULE , TUNER E1C CNVKST-MT004MV1-2

Denon AVR-3312 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Speaker selector	A+B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.8 %
Power output per channel (1KHz@8 Ohm)	165 W
Power output per channel (20-20KHz@8 Ohm)	125 W
HDMI in	7
Audio (L/R) in	8
Composite video in	5
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	2
Composite video out	3
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Internet radio services supported	Last.fm, Napster
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Display	VFL
HDMI version	1.4a
Product color	Black
Audio decoders	Dolby Pro Logic IIz, Dolby TrueHD, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	iPad, iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	670 W
Card reader integrated	-
Cables included	AC

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	11800 g
