Denon AVR-3312 Service Manual

214
Ref. No. Part No. Part Name Remarks Q'ty New
C4875-4878 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C4881,4882 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C4887,4888 nsp CAP, CHIP(1608, 50V/3300pF) CCUS1H332KC
C4889,4890 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C4891,4892 943134010610S ELECT CAP 4.7UF 50V CCEA1HH4R7T
C4893 943134501580S CAP , ELECT(25V/33uF) CCEA1EH330T *
C4894 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C4895 943134501580S CAP , ELECT(25V/33uF) CCEA1EH330T *
OTHERS PARTS GROUP
BN203 nsp
WIRE ASS'Y
(3P,2.0MM,100MM,UL1569#26,105)
CWB7B003100LC
BN461 nsp
WIRE ASS'Y LOCKING
(13P,2.0MM,220MM,UL1007#26)
CWB1B013220HC
CN41B nsp
PIN SOCKET (15P,1.25mm,ANGLE, B-TO-B) CJP15HJ282Z
CN42B nsp
PIN SOCKET (27P,1.25mm,ANGLE, B-TO-B) CJP27HJ282Z
CN43B nsp
PIN SOCKET (15P,1.25mm,ANGLE, B-TO-B) CJP15HJ282Z
CN44B nsp
PIN SOCKET (17P,1.25mm,ANGLE, B-TO-B) P CJP17HJ282Z
CN45B nsp
PIN SOCKET (11P,1.25mm,ANGLE, B-TO-B) CJP11HJ282Z
JK461-463 643010076005S JACK, 4P(W/R,W/R),SEPA-GND, SILVER CJJ4P048Z
JK466 943643010150S JACK NOSPCC2PW/R CJJ4N034U
JW203 nsp
WIRE ASS'Y RING
(1P,150MM,BLK,UL1569#22,CKM-T)
CWE6702150ST
L4661,4662 nsp COIL, TOROIDAL E2,E1C C L U 9 S 0 0 4 Z

Denon AVR-3312 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Speaker selector	A+B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.8 %
Power output per channel (1KHz@8 Ohm)	165 W
Power output per channel (20-20KHz@8 Ohm)	125 W
HDMI in	7
Audio (L/R) in	8
Composite video in	5
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	2
Composite video out	3
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Internet radio services supported	Last.fm, Napster
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Display	VFL
HDMI version	1.4a
Product color	Black
Audio decoders	Dolby Pro Logic IIz, Dolby TrueHD, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	iPad, iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	670 W
Card reader integrated	-
Cables included	AC

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	11800 g
