Conrmation item Setting and display Details of how to operate remote controller *a)
Output sequence of remote control codes
※
It is useful to form a macro program. *b)
Contents of conrmation Remarks
4
Analog or HDMI to HDMI (signal) Path Video Convert(IP Scaler) : ON, All Sources
IP Scaler : Analog & HDMI , All Sources
Resolution : "AUTO", All Sources
Display:
V 0 2 D V D
1.Press [AMP]
2.Press [ZONE SELECT] , Select "ZONE2"
3.Press [ZONE OFF]
q
ZONE2 POWER OFF ·Input CVBS / Through : IP Scaler / Output : HDMI
·Input S-VIDEO / Through : IP Scaler / Output : HDMI
·Input Component / Through : IP Scaler / Output : HDMI
·Input HDMI / Through : IP Scaler / Output : HDMI
(
※
As the input source, you can switch from DVD to other ones.)
Conrm the input pass one by one.
Because it becomes only the input of the highest input
becomes Convert/IP Scaler (signal) Path if it inputs it at
the same time.
(HDMI input > Component input > S-VIDEO input >
CVBS input)
4.Press [ZONE SELECT], Select "ZONE3"
5.Press [ZONE OFF]
w
ZONE3 POWER OFF
6.Press [ZONE SELECT], Select "MAIN"
7.Press [2/ABC]
e
KEY 2/ABC (Main Zone)
Initialization & Video Convert All ON & IP
Scaler "Analog & HDMI"
8.Press [DVD]
r
DVD (Main Zone)
5
OSD FUNCTION Video Convert(IP Scaler) : ON, All Sources
IP Scaler : Analog & HDMI , All Sources
Resolution : "AUTO", All Sources
Menu : ON
All ZONE :ON
Display:
V 0 2 D V D
1.Press [AMP]
2.Press [ZONE SELECT] , Select "ZONE2"
3.Press [ZONE OFF]
q
ZONE2 POWER OFF ·OSD Display / Output : CVBS
·OSD Display / Output : Component
·OSD Display / Output : HDMI
(
※
As the input source, you can switch from DVD to other ones.)
Connect HDMI Monitor OUT / Output : OSD from HDMI
No connect HDMI Monitor OUT / Output : OSD from
Component
No output other terminal.
※
AVR2312/3312 are nothing ZONE2 OSD
4.Press [ZONE SELECT], Select "ZONE3"
5.Press [ZONE OFF]
w
ZONE3 POWER OFF
6.Press [ZONE SELECT], Select "MAIN"
7.Press [2/ABC]
e
KEY 2/ABC (Main Zone)
Initialization &VideoConvert All ON & IP
Scaler"Analog&HDMI"
8.Press [ZONE SELECT], Select "ZONE2"
9.Press [ZONE ON]
r
ZONE2 POWER ON
10.Press [ZONE SELECT], Select "ZONE3"
11.Press [ZONE ON]
t
ZONE3 POWER ON
12.Press [ZONE SELECT], Select "MAIN"
13.Press [DVD]
y
DVD (Main Zone)
14.Press [AMP]
15.Press [MENU]
u
GUI MENU (Main Zone)
6
CEC FUNCTION
(Control Monitor : HDMI Monitor1)
HDMI Control : ON
Control Monitor Monitor1 (When checking the
HDMI Monitor Out1)
Display:
V 0 3 D V D
1.Press [AMP]
2.Press [ZONE SELECT] , Select "ZONE2"
3.Press [ZONE OFF]
q
ZONE2 POWER OFF
· When the power supply of a TV is put in the standby mode, make sure
that the power supply of this unit is also put in the standby mode.
(
※
As the input source, you can switch from DVD to other ones.)
4.Press [ZONE SELECT], Select "ZONE3"
5.Press [ZONE OFF]
w
ZONE3 POWER OFF
6.Press [ZONE SELECT], Select "MAIN"
7.Press [3/DEF]
e
KEY 3/DEF (Main Zone)
Initialization & CEC Control ON & Select
Control Monitor 1
8.Press [DVD]
r
DVD (Main Zone)
7
CEC FUNCTION
(Control Monitor : HDMI Monitor 2)
HDMI Control : ON
Control Monitor Monitor 2 (When checking the
HDMI Monitor Out 2)
Display:
V 0 4 D V D
1.Press [AMP]
2.Press [ZONE SELECT] , Select "ZONE2"
3.Press [ZONE OFF]
q
ZONE2 POWER OFF When the power supply of a TV is put in the standby mode, make sure
that the power supply of this unit is also put in the standby mode.
(
※
As the input source, you can switch from DVD to other ones.)
only AVR3312
4.Press [ZONE SELECT], Select "ZONE3"
5.Press [ZONE OFF]
w
ZONE3 POWER OFF
6.Press [ZONE SELECT], Select "MAIN"
7.Press [4/GHI]
e
KEY 4/GHI (Main Zone)
Initialization & CEC Control ON & Select
Control Monitor 2
8.Press [DVD]
r
DVD (Main Zone)
8
HDMI Audio (signal) Path
(Audio : AMP)
Audio : AMP(When checking the audio output
from AMP)
Display:
V 0 5 D V D
1.Press [AMP]
2.Press [ZONE SELECT], Select "ZONE2"
3.Press [ZONE OFF]
q
ZONE2 POWER OFF ·Input : HDMI (Signal of PCM, DolbyDigital or DTS) / Output : Speakers
·Input : HDMI (Signal of HD Audio) / Output : Speakers
(
※
As the input source, you can switch from DVD to other ones.)
4.Press [ZONE SELECT], Select "ZONE3"
5.Press [ZONE OFF]
w
ZONE3 POWER OFF
6.Press [ZONE SELECT], Select "MAIN"
7.Press [5/JKL]
e
KEY 5/JKL (Main Zone)
Initialization & Select Audio AMP
8.Press [DVD]
r
DVD (Main Zone)
9
HDMI Audio (signal) Path
(Audio : TV)
Audio : TV(When checking the audio output
from TV)
Display:
V 0 6 D V D
1.Press [AMP]
2.Press [ZONE SELECT] , Select "ZONE2"
3.Press [ZONE OFF]
q
ZONE2 POWER OFF
· Input : HDMI (Signal of PCM or DolbyDigital or DTS) / Output : HDMI
(Audio output from connected TV)
(
※
As the input source, you can switch from DVD to other ones.)
4.Press [ZONE SELECT], Select "ZONE3"
5.Press [ZONE OFF]
w
ZONE3 POWER OFF
6.Press [ZONE SELECT], Select "MAIN"
7.Press [6/MNO]
e
KEY 6/MNO (Main Zone)
Initialization & Audio Select TV
8.Press [DVD]
r
DVD (Main Zone)
