Denon AVR-3312 Service Manual

72
Error
Code
Details of Error code Display Coping strategies
A0
Acquisition of (Application Mode)
IP address failed before rewriting
DM860 was rewritten (AutoIP).
E t h e r I M G * * * m i n
C o n n e c t i o n F a i l A 0
Check the network connection.
Carry out the update in an environment
that has little network load.
A1
Acquisition of (Application Mode)
IP address failed before rewriting
DM860 was rewritten (when timed
out).
E t h e r I M G * * * m i n
C o n n e c t i o n F a i l A 1
Check the network connection.
Carry out the update in an environment
that has little network load.
A2
Invalid login via DPMS access was
notied DM860 related rmware
was rewritten (Application Mode).
E t h e r I M G * * * m i n
L o g i n f a i l e d A 2
Check the network connection.
Carry out the update in an environment
that has little network load.
A3
Line congestion via DPMS access
was notied DM860 related rmware
was rewritten (Application Mode).
E t h e r I M G * * * m i n
S e r v e r i s b u s y A 3
Check the network connection.
Carry out the update in an environment
that has little network load.
A4
Connection failure via DPMS
access was notied DM860 related
rmware was rewritten (Application
Mode).
E t h e r I M G * * * m i n
C o n n e c t i o n F a i l A 4
Check the network connection.
Carry out the update in an environment
that has little network load.
A6
Firmware data error message
was received after DPMS login
when DM860 related rmware was
rewritten (Application Mode).
E t h e r I M G * * * m i n
U p d a t i n g f a i l A 6
Turn off and on the power. Updating
starts automatically.
Carry out the update in an environment
that has little network load.
A7
When DM860 related rmware
was rewritten (Application Mode),
request was made for rmware data
after DPMS login but it timed out.
E t h e r I M G * * * m i n
U p d a t i n g f a i l A 7
Turn off and on the power. Updating
starts automatically.
Carry out the update in an environment
that has little network load.
A8
Acquisition of (Boot Loader Mode)
IP address failed before rewriting
DM860 was rewritten (AutoIP).
E t h e r I M G * * * m i n
C o n n e c t i o n F a i l A 8
Check the network connection.
Carry out the update in an environment
that has little network load.
A9
Acquisition of (Boot Loader Mode)
IP address failed before rewriting
DM860 was rewritten (when timed
out).
E t h e r I M G * * * m i n
C o n n e c t i o n F a i l A 9
Check the network connection.
Carry out the update in an environment
that has little network load.
AA
Invalid login via DPMS access failed
when DM860 related rmware was
rewritten (Boot Loader Mode).
E t h e r I M G * * * m i n
L o g i n f a i l e d A A
Check the network connection.
Carry out the update in an environment
that has little network load.
AB
Line congestion via DPMS access
when DM860 related rmware was
rewritten (Boot Loader Mode).
E t h e r I M G * * * m i n
S e r v e r i s b u s y A B
Check the network connection.
Carry out the update in an environment
that has little network load.
AC
Connection failure via DPMS
access failed when DM860 related
rmware was rewritten (Boot Loader
Mode).
E t h e r I M G * * * m i n
C o n n e c t i o n F a i l A C
Check the network connection.
Carry out the update in an environment
that has little network load.
AE
Firmware download error message
received (when download fails)
when DM860 related rmware was
rewritten (Boot Loader Mode).
E t h e r I M G * * * m i n
D o w n l o a d f a i l A E
Turn off and on the power. Updating
starts automatically.
Carry out the update in an environment
that has little network load.
AF
Firmware download error message
received (line congestion) when
DM860 related rmware was
rewritten (Boot Loader Mode).
E t h e r I M G * * * m i n
S e r v e r i s b u s y A F
Turn off and on the power. Updating
starts automatically.
Carry out the update in an environment
that has little network load.
B0
Firmware download error message
received (connection failure) when
DM860 related rmware was
rewritten (Boot Loader Mode).
E t h e r I M G * * * m i n
C o n n e c t i o n F a i l B 0
Turn off and on the power. Updating
starts automatically.
Carry out the update in an environment
that has little network load.
B2
Error message received when
DM860 related rmware was
rewritten
E t h e r I M G * * * m i n
U p d a t i n g f a i l B 2
Turn off and on the power. Updating
starts automatically.
Carry out the update in an environment
that has little network load.

Denon AVR-3312 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Speaker selector	A+B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.8 %
Power output per channel (1KHz@8 Ohm)	165 W
Power output per channel (20-20KHz@8 Ohm)	125 W
HDMI in	7
Audio (L/R) in	8
Composite video in	5
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	2
Composite video out	3
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Internet radio services supported	Last.fm, Napster
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Display	VFL
HDMI version	1.4a
Product color	Black
Audio decoders	Dolby Pro Logic IIz, Dolby TrueHD, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	iPad, iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	670 W
Card reader integrated	-
Cables included	AC

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	11800 g
