Denon AVR-3312 Service Manual

84
VIDEO B'D aw.
VIDEO B'D aw.
B
NO
NO
NO
NO
YES
YES
YES
YES
Is the signal output from
IC551(AVDM-2000)?
V : J5227/J5137
COMPONENT(Y) : J5134/J5133
COMPONENT(Cb) : J5135
COMPONENT(Cr) : J5136
Is the signal output from
IC554(BD7628)?
S(Y) : J5114/J5204
S(C) : J5115
Is the signal input to
IC551(AVDM-2000)?
V : J5195
COMPONENT(Y) : J5241
COMPONENT(Cb) : J5233
COMPONENT(Cr) : J5235
Is the signal input to
IC552(BU4052)?
S(Y) : J5280
S(C) : J5287
C
Extend HDMI B'D using a jig.
Extend HDMI B'D using a jig.
The parts between IC551 and
JK551 or JK557 are defective.
The pattern between IC55
2
and JK553 are defective.
The soldering (IC551) is defective.
IC552 and IC554, and
surrounding circuitry soldering
are defective.
FRONT CONNECTOR B'D aw
or defective connection of the
connector.
FRONT CONNECTOR B'D aw
or defective connection of the
connector.

Denon AVR-3312 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Speaker selector	A+B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.8 %
Power output per channel (1KHz@8 Ohm)	165 W
Power output per channel (20-20KHz@8 Ohm)	125 W
HDMI in	7
Audio (L/R) in	8
Composite video in	5
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	2
Composite video out	3
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Internet radio services supported	Last.fm, Napster
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Display	VFL
HDMI version	1.4a
Product color	Black
Audio decoders	Dolby Pro Logic IIz, Dolby TrueHD, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	iPad, iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	670 W
Card reader integrated	-
Cables included	AC

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	11800 g
