Denon AVR-4306 Service Manual

69
AVR-4306/AVC-4320
RESISTORS GROUP
VR601-605 00D 211 6148 906 V03PB471MT(RH03ADCS) +REF
CAPACITORS GROUP
C101 nsp 00D 257 0516 954 CK73B1E104KT +1608
C102 00D 257 2015 903 CS77B1A100MT
C104 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C105 00D 257 3024 964 CF73=1C104JT(ECHUX)
C107 00D 257 3023 981 CF73=1C223JT(ECHUX)
C108 nsp 00D 257 0516 954 CK73B1E104KT +1608
C109 00D 257 2015 903 CS77B1A100MT
C111 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C112 00D 257 3024 964 CF73=1C104JT(ECHUX)
C114 00D 257 3023 981 CF73=1C223JT(ECHUX)
C115 nsp 00D 257 0516 954 CK73B1E104KT +1608
C116 00D 257 2015 903 CS77B1A100MT
C118 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C119 00D 257 3024 964 CF73=1C104JT(ECHUX)
C121 00D 257 3023 981 CF73=1C223JT(ECHUX)
C122-127 nsp 00D 257 0509 929 CK73B1H102KT +1608
C202 nsp 00D 257 0516 954 CK73B1E104KT +1608
C203 nsp 00D 257 0509 929 CK73B1H102KT +1608
C204-208 nsp 00D 257 0516 954 CK73B1E104KT +1608
C209-213 nsp 00D 257 0509 929 CK73B1H102KT +1608
C214,215 00D 257 2015 903 CS77B1A100MT
C216,217 nsp 00D 257 0516 954 CK73B1E104KT +1608
C218 nsp 00D 257 0509 929 CK73B1H102KT +1608
C219-222 nsp 00D 257 0516 954 CK73B1E104KT +1608
C223 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C225-232 nsp 00D 257 0516 954 CK73B1E104KT +1608
C233-236 nsp 00D 257 0509 929 CK73B1H102KT +1608
C237 nsp 00D 257 0503 941 CC73CH1H120JT +1608
C238 nsp 00D 257 0509 929 CK73B1H102KT +1608
C239 nsp 00D 257 5008 946 CK73B1E103KT(1005)
C240 nsp 00D 257 0503 941 CC73CH1H120JT +1608
C241 nsp 00D 257 0509 929 CK73B1H102KT +1608
C242 nsp 00D 257 5006 993 CK73B1H102KT +1005
C243-249 nsp 00D 257 0509 929 CK73B1H102KT +1608
C253 00D 257 2015 903 CS77B1A100MT
C255 nsp 00D 257 0509 929 CK73B1H102KT +1608
C260 00D 257 2015 903 CS77B1A100MT
C261,262 nsp 00D 257 0516 954 CK73B1E104KT +1608
C263 00D 257 2015 903 CS77B1A100MT
C264 nsp 00D 257 0516 954 CK73B1E104KT +1608
C265 nsp 00D 257 0509 929 CK73B1H102KT +1608
C266 nsp 00D 257 0516 954 CK73B1E104KT +1608
C267 00D 257 2015 903 CS77B1A100MT
C301,302 00D 257 3018 925 CF73=1H102JT(ECHUX)
C303-306 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C307,308 00D 254 4465 921 CE67C1C100MT +REF
C310,311 nsp 00D 257 0509 929 CK73B1H102KT +1608
C312 nsp 00D 257 0516 954 CK73B1E104KT +1608
C313 00D 254 4465 921 CE67C1C100MT +REF
C314 00D 254 4601 934 CE67W0J101MT(P.CAP) +REF
C315-318 00D 254 4465 921 CE67C1C100MT +REF
C319 00D 257 2015 903 CS77B1A100MT
C320 00D 254 4465 921 CE67C1C100MT +REF
C321 nsp 00D 257 0516 954 CK73B1E104KT +1608
C322 nsp 00D 257 0509 929 CK73B1H102KT +1608
C323 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C324-326 nsp 00D 257 0516 954 CK73B1E104KT +1608
C327,328 00D 257 2015 903 CS77B1A100MT
C329 00D 257 3018 941 CF73=1H152JT(ECHUX)
C330 00D 257 3018 954 CF73=1H182JT(ECHUX)
C331 00D 257 3017 971 CF73=1H391JT(ECHUX)
Ref. No. nsp Part No. Part Name Remarks Q'ty New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-4306 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	102 dB
Dynamic power per channel (4 Ohm)	220 W
Dynamic power per channel (8 Ohm)	150 W
Power output per channel (1KHz@6 Ohm)	170 W
Power output per channel (20-20KHz@8 Ohm)	130 W
HDMI in	3
Line-in	Yes
Composite video in	7
USB ports quantity	1
Digital audio coaxial in	2
Digital audio optical in	5
Headphone connectivity	3.5 mm
Speakers connectivity type	RCA
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	1 W
Power consumption (typical)	570 W
3D	-
Optical drive included	No
Product color	Silver
Audio decoders	DTS 96/24, DTS Neo:6, DTS-ES, Dolby Digital, Dolby Digital EX, Dolby Pro Logic IIx
Apple docking compatibility	iPod

Weight and Dimensions

Depth	429 mm
Width	434 mm
Height	171 mm
Weight	18500 g
