Denon AVR-4306 Service Manual

70
AVR-4306/AVC-4320
C332 00D 257 3017 997 CF73=1H561JT(ECHUX)
C333 00D 257 3017 971 CF73=1H391JT(ECHUX)
C334 00D 257 3017 997 CF73=1H561JT(ECHUX)
C335,336 00D 254 4603 916 CE67W1E100MT(P.CAP) +REF
C337,338 nsp 00D 257 0516 954 CK73B1E104KT +1608
C339,340 00D 257 2015 903 CS77B1A100MT
C341 00D 257 3018 954 CF73=1H182JT(ECHUX)
C342 00D 257 3018 941 CF73=1H152JT(ECHUX)
C343 00D 257 3017 997 CF73=1H561JT(ECHUX)
C344 00D 257 3017 971 CF73=1H391JT(ECHUX)
C345 00D 257 3017 997 CF73=1H561JT(ECHUX)
C346 00D 257 3017 971 CF73=1H391JT(ECHUX)
C347,348 00D 257 2015 903 CS77B1A100MT
C349,350 nsp 00D 257 0516 954 CK73B1E104KT +1608
C351 nsp 00D 257 0509 929 CK73B1H102KT +1608
C352 00D 257 2015 903 CS77B1A100MT
C353,354 00D 257 3018 954 CF73=1H182JT(ECHUX)
C355-358 00D 257 3017 997 CF73=1H561JT(ECHUX)
C359,360 nsp 00D 257 0516 954 CK73B1E104KT +1608
C361 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C362 00D 257 2015 903 CS77B1A100MT
C363 00D 257 3018 941 CF73=1H152JT(ECHUX)
C364 00D 257 3018 954 CF73=1H182JT(ECHUX)
C365 00D 257 3017 926 CF73=1H151JT(ECHUX)
C366 00D 257 3017 997 CF73=1H561JT(ECHUX)
C367 00D 257 3017 926 CF73=1H151JT(ECHUX)
C368 00D 257 3017 997 CF73=1H561JT(ECHUX)
C369 nsp 00D 257 0516 954 CK73B1E104KT +1608
C370 nsp 00D 257 0509 929 CK73B1H102KT +1608
C371,372 00D 257 2015 903 CS77B1A100MT
C375,376 00D 257 2015 903 CS77B1A100MT
C377 00D 254 4601 934 CE67W0J101MT(P.CAP) +REF
C401,402 nsp 00D 257 0516 954 CK73B1E104KT +1608
C403 nsp 00D 257 0509 929 CK73B1H102KT +1608
C404-408 nsp 00D 257 0516 954 CK73B1E104KT +1608
C409-413 nsp 00D 257 0509 929 CK73B1H102KT +1608
C414 00D 257 2015 903 CS77B1A100MT
C416 00D 257 2015 903 CS77B1A100MT
C417,418 nsp 00D 257 0516 954 CK73B1E104KT +1608
C420 nsp 00D 257 0509 929 CK73B1H102KT +1608
C421-424 nsp 00D 257 0516 954 CK73B1E104KT +1608
C425,426 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C427-434 nsp 00D 257 0516 954 CK73B1E104KT +1608
C435-438 nsp 00D 257 0509 929 CK73B1H102KT +1608
C439 nsp 00D 257 0503 941 CC73CH1H120JT +1608
C440 nsp 00D 257 0509 929 CK73B1H102KT +1608
C441 nsp 00D 257 5008 946 CK73B1E103KT(1005)
C442 nsp 00D 257 0503 941 CC73CH1H120JT +1608
C443 nsp 00D 257 0509 929 CK73B1H102KT +1608
C444 nsp 00D 257 5006 993 CK73B1H102KT +1005
C445-451 nsp 00D 257 0509 929 CK73B1H102KT +1608
C455 00D 257 2015 903 CS77B1A100MT
C457 nsp 00D 257 0509 929 CK73B1H102KT +1608
C462 00D 257 2015 903 CS77B1A100MT
C463,464 nsp 00D 257 0516 954 CK73B1E104KT +1608
C465 00D 257 2015 903 CS77B1A100MT
C466 nsp 00D 257 0516 954 CK73B1E104KT +1608
C467 nsp 00D 257 0509 929 CK73B1H102KT +1608
C468 nsp 00D 257 0516 954 CK73B1E104KT +1608
C469 00D 257 2015 903 CS77B1A100MT
C501 00D 257 2015 903 CS77B1A100MT
C502,503 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C504 00D 257 2015 903 CS77B1A100MT
C505,506 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C507 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C508 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
Ref. No. nsp Part No. Part Name Remarks Q'ty New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-4306 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	102 dB
Dynamic power per channel (4 Ohm)	220 W
Dynamic power per channel (8 Ohm)	150 W
Power output per channel (1KHz@6 Ohm)	170 W
Power output per channel (20-20KHz@8 Ohm)	130 W
HDMI in	3
Line-in	Yes
Composite video in	7
USB ports quantity	1
Digital audio coaxial in	2
Digital audio optical in	5
Headphone connectivity	3.5 mm
Speakers connectivity type	RCA
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	1 W
Power consumption (typical)	570 W
3D	-
Optical drive included	No
Product color	Silver
Audio decoders	DTS 96/24, DTS Neo:6, DTS-ES, Dolby Digital, Dolby Digital EX, Dolby Pro Logic IIx
Apple docking compatibility	iPod

Weight and Dimensions

Depth	429 mm
Width	434 mm
Height	171 mm
Weight	18500 g
