Denon AVR-4306 Service Manual

71
AVR-4306/AVC-4320
C509 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C510 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C511,512 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C513 00D 257 2015 903 CS77B1A100MT
C515 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C516 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C517,518 nsp 00D 257 0516 954 CK73B1E104KT +1608
C519 00D 257 2015 903 CS77B1A100MT
C520-524 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C525 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C526-530 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C531-539 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C540 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C541 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C542 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C543 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C601 nsp 00D 257 0516 954 CK73B1E104KT +1608
C603 nsp 00D 257 0516 954 CK73B1E104KT +1608
C605 nsp 00D 257 0516 954 CK73B1E104KT +1608
C606 00D 257 2015 903 CS77B1A100MT
C609-613 nsp 00D 257 0516 954 CK73B1E104KT +1608
C614,615 00D 254 4572 908 CE67C1C100MT(MV-B) +REF
C617,618 00D 254 4572 908 CE67C1C100MT(MV-B) +REF
C619,620 nsp 00D 257 0516 954 CK73B1E104KT +1608
C621,622 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C624-628 nsp 00D 257 0516 954 CK73B1E104KT +1608
C629 nsp 00D 257 0509 929 CK73B1H102KT +1608
C630 nsp 00D 257 0516 954 CK73B1E104KT +1608
C632 00D 257 3023 949 CF73=1C103JT(ECHUX)
C633 00D 257 3024 951 CF73=1C823JT(ECHUX)
C634 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C636 nsp 00D 257 0516 954 CK73B1E104KT +1608
C638 nsp 00D 257 0516 954 CK73B1E104KT +1608
C639,640 nsp 00D 257 0502 984 CC73CH1H6R0DT +1608
C642 nsp 00D 257 0516 954 CK73B1E104KT +1608
C643 00D 254 4464 906 CE67C0J101MT +REF
C644 nsp 00D 257 0509 929 CK73B1H102KT +1608
C645 00D 257 2015 903 CS77B1A100MT
C646-648 nsp 00D 257 0509 929 CK73B1H102KT +1608
C649 00D 257 2015 903 CS77B1A100MT
C650,651 nsp 00D 257 0509 929 CK73B1H102KT +1608
C652 00D 257 2015 903 CS77B1A100MT
C653 00D 254 4464 906 CE67C0J101MT +REF
C654 nsp 00D 257 0509 929 CK73B1H102KT +1608
C655 00D 257 2015 903 CS77B1A100MT
C656-658 nsp 00D 257 0509 929 CK73B1H102KT +1608
C659 00D 257 2015 903 CS77B1A100MT
C662,663 nsp 00D 257 0516 954 CK73B1E104KT +1608
C665 00D 257 2015 903 CS77B1A100MT
C666,667 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C669 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C670,671 nsp 00D 257 0516 954 CK73B1E104KT +1608
C672 00D 257 3018 912 CF73=1H821JT(ECHUX)
C674 nsp 00D 257 0516 954 CK73B1E104KT +1608
C675 00D 257 3022 995 CF73=1C392JT(ECHUX)
C683-687 nsp 00D 257 0516 954 CK73B1E104KT +1608
C717 nsp 00D 257 5006 993 CK73B1H102KT +1005
C718 nsp 00D 257 5008 933 CK73B1A104KT +1005
C719 00D 257 2015 903 CS77B1A100MT
C720-723 nsp 00D 257 5006 993 CK73B1H102KT +1005
C724 nsp 00D 257 5008 933 CK73B1A104KT +1005
C726-728 nsp 00D 257 5006 993 CK73B1H102KT +1005
C751,752 nsp 00D 257 5008 933 CK73B1A104KT +1005
C753 nsp 00D 257 5008 946 CK73B1E103KT(1005)
C754-757 nsp 00D 257 5008 933 CK73B1A104KT +1005
C758 nsp 00D 257 5008 946 CK73B1E103KT(1005)
Ref. No. nsp Part No. Part Name Remarks Q'ty New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-4306 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	102 dB
Dynamic power per channel (4 Ohm)	220 W
Dynamic power per channel (8 Ohm)	150 W
Power output per channel (1KHz@6 Ohm)	170 W
Power output per channel (20-20KHz@8 Ohm)	130 W
HDMI in	3
Line-in	Yes
Composite video in	7
USB ports quantity	1
Digital audio coaxial in	2
Digital audio optical in	5
Headphone connectivity	3.5 mm
Speakers connectivity type	RCA
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	1 W
Power consumption (typical)	570 W
3D	-
Optical drive included	No
Product color	Silver
Audio decoders	DTS 96/24, DTS Neo:6, DTS-ES, Dolby Digital, Dolby Digital EX, Dolby Pro Logic IIx
Apple docking compatibility	iPod

Weight and Dimensions

Depth	429 mm
Width	434 mm
Height	171 mm
Weight	18500 g
