Denon AVR-4306 Service Manual

72
AVR-4306/AVC-4320
C759 nsp 00D 257 5008 933 CK73B1A104KT +1005
C760 nsp 00D 257 5008 946 CK73B1E103KT(1005)
C761 nsp 00D 257 5008 933 CK73B1A104KT +1005
C762 00D 257 2015 903 CS77B1A100MT
C763 nsp 00D 257 5008 946 CK73B1E103KT(1005)
C764 nsp 00D 257 5008 933 CK73B1A104KT +1005
C765 00D 257 2015 903 CS77B1A100MT
C766-773 nsp 00D 257 5008 933 CK73B1A104KT +1005
C774,775 nsp 00D 257 0503 983 CC73CH1H180JT +1608
C776-779 nsp 00D 257 5008 933 CK73B1A104KT +1005
C780 nsp 00D 257 5008 946 CK73B1E103KT(1005)
C781 00D 257 2015 903 CS77B1A100MT
C782-789 nsp 00D 257 5008 933 CK73B1A104KT +1005
C790 00D 257 2015 903 CS77B1A100MT
C791,792 nsp 00D 257 0516 954 CK73B1E104KT +1608
C793-796 nsp 00D 257 0509 929 CK73B1H102KT +1608
C797 nsp 00D 257 0516 954 CK73B1E104KT +1608
C801 nsp 00D 257 0509 929 CK73B1H102KT +1608
C802 00D 257 2015 903 CS77B1A100MT
C803 nsp 00D 257 0503 996 CC73CH1H200JT +1608
C804 00D 254 4465 905 CE67C1C220MT +REF
C808-810 nsp 00D 257 0503 996 CC73CH1H200JT +1608
C811,812 nsp 00D 257 0516 954 CK73B1E104KT +1608
C814 nsp 00D 257 0516 954 CK73B1E104KT +1608
C815 00D 257 2015 903 CS77B1A100MT
C816 nsp 00D 257 0516 954 CK73B1E104KT +1608
C818 nsp 00D 257 0509 929 CK73B1H102KT +1608
C821 00D 257 0039 907 CK73B0J106MT
C822 nsp 00D 257 0516 954 CK73B1E104KT +1608
C824 nsp 00D 257 0516 954 CK73B1E104KT +1608
C825-827 nsp 00D 257 0509 929 CK73B1H102KT +1608
C829 nsp 00D 257 0509 929 CK73B1H102KT +1608
C830 nsp 00D 257 0516 954 CK73B1E104KT +1608
C834,835 nsp 00D 257 0516 954 CK73B1E104KT +1608
C844 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C845 nsp 00D 257 0509 929 CK73B1H102KT +1608
C846 00D 254 4465 921 CE67C1C100MT +REF
C847 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C848 nsp 00D 257 0509 929 CK73B1H102KT +1608
C850 00D 254 4601 905 CE67W0J331MT(P.CAP) +REF
C851 00D 257 2015 903 CS77B1A100MT
C852,853 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C854 00D 254 4601 905 CE67W0J331MT(P.CAP) +REF
C855 00D 257 2015 903 CS77B1A100MT
C856 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C901-903 nsp 00D 257 0516 954 CK73B1E104KT +1608
C904-906 nsp 00D 257 0509 929 CK73B1H102KT +1608
C907 nsp 00D 257 0516 954 CK73B1E104KT +1608
C908-911 nsp 00D 257 5008 933 CK73B1A104KT +1005
C912 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C913 nsp 00D 257 0509 929 CK73B1H102KT +1608
C915 nsp 00D 257 0516 954 CK73B1E104KT +1608
C916 nsp 00D 257 0509 929 CK73B1H102KT +1608
C919-921 nsp 00D 257 0516 954 CK73B1E104KT +1608
C922 00D 257 2015 903 CS77B1A100MT
C923,924 nsp 00D 257 0516 954 CK73B1E104KT +1608
C925,926 00D 254 4464 906 CE67C0J101MT +REF
C927,928 nsp 00D 257 0503 925 CC73CH1H100DT +1608
C929,930 nsp 00D 257 0516 954 CK73B1E104KT +1608
C931,932 nsp 00D 257 0509 929 CK73B1H102KT +1608
C933 nsp 00D 257 0503 925 CC73CH1H100DT +1608
C934,935 nsp 00D 257 5008 933 CK73B1A104KT +1005
C936 nsp 00D 257 5006 993 CK73B1H102KT +1005
C937 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C938 00D 257 2015 903 CS77B1A100MT
C939 nsp 00D 257 5006 993 CK73B1H102KT +1005
Ref. No. nsp Part No. Part Name Remarks Q'ty New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-4306 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	102 dB
Dynamic power per channel (4 Ohm)	220 W
Dynamic power per channel (8 Ohm)	150 W
Power output per channel (1KHz@6 Ohm)	170 W
Power output per channel (20-20KHz@8 Ohm)	130 W
HDMI in	3
Line-in	Yes
Composite video in	7
USB ports quantity	1
Digital audio coaxial in	2
Digital audio optical in	5
Headphone connectivity	3.5 mm
Speakers connectivity type	RCA
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	1 W
Power consumption (typical)	570 W
3D	-
Optical drive included	No
Product color	Silver
Audio decoders	DTS 96/24, DTS Neo:6, DTS-ES, Dolby Digital, Dolby Digital EX, Dolby Pro Logic IIx
Apple docking compatibility	iPod

Weight and Dimensions

Depth	429 mm
Width	434 mm
Height	171 mm
Weight	18500 g
