Denon AVR-4306 Service Manual

73
AVR-4306/AVC-4320
C940-951 nsp 00D 257 0516 954 CK73B1E104KT +1608
C952-959 nsp 00D 257 0509 929 CK73B1H102KT +1608
C960 00D 257 2015 903 CS77B1A100MT
C961 nsp 00D 257 0509 929 CK73B1H102KT +1608
C962 nsp 00D 257 0516 954 CK73B1E104KT +1608
C963 nsp 00D 257 0509 929 CK73B1H102KT +1608
C964 00D 257 2015 903 CS77B1A100MT
C965,966 nsp 00D 257 0509 929 CK73B1H102KT +1608
C967 00D 257 2015 903 CS77B1A100MT
C968 nsp 00D 257 0509 929 CK73B1H102KT +1608
C969 00D 254 4465 918 CE67C1C470MT +REF
C970,971 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C972 nsp 00D 257 0516 954 CK73B1E104KT +1608
C973 nsp 00D 257 0509 929 CK73B1H102KT +1608
C974 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C975,976 nsp 00D 257 5008 933 CK73B1A104KT +1005
C977 nsp 00D 257 0516 954 CK73B1E104KT +1608
C978 00D 254 4464 906 CE67C0J101MT +REF
C979 nsp 00D 257 0516 954 CK73B1E104KT +1608
C980 00D 257 2015 903 CS77B1A100MT
C981 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C982 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C983 nsp 00D 257 0503 925 CC73CH1H100DT +1608
C984 nsp 00D 257 0509 929 CK73B1H102KT +1608
C985 nsp 00D 257 0516 954 CK73B1E104KT +1608
C986 nsp 00D 257 0509 929 CK73B1H102KT +1608
C987 00D 257 2015 903 CS77B1A100MT
C988 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C989 nsp 00D 257 0509 929 CK73B1H102KT +1608
C990,991 00D 257 2015 903 CS77B1A100MT
C992 nsp 00D 257 0516 954 CK73B1E104KT +1608
CC151 00D 257 2015 903 CS77B1A100MT
CC152-157 nsp 00D 257 5006 993 CK73B1H102KT +1005
CC158,159 nsp 00D 257 5006 993 CK73B1H102KT +1005
CC160-167 nsp 00D 257 5004 966 CC73CH1H101JT +1005
CC168 nsp 00D 257 0506 951 CC73CH1H101JT +1608
CC169,170 nsp 00D 257 0509 929 CK73B1H102KT +1608
CC171 nsp 00D 257 0506 951 CC73CH1H101JT +1608
CC172 00D 254 4601 918 CE67W0J471MT(P.CAP) +REF
CC251,252 nsp 00D 257 0503 925 CC73CH1H100DT +1608
CC253 00D 257 2015 903 CS77B1A100MT
CC254,255 nsp 00D 257 5006 993 CK73B1H102KT +1005
CC256,257 nsp 00D 257 5004 966 CC73CH1H101JT +1005
CC258,259 nsp 00D 257 0516 954 CK73B1E104KT +1608
CC260 nsp 00D 257 0506 951 CC73CH1H101JT +1608
CC261 nsp 00D 257 0516 954 CK73B1E104KT +1608
CC262 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
CC263 nsp 00D 257 0509 929 CK73B1H102KT +1608
CC266,267 nsp 00D 257 0516 954 CK73B1E104KT +1608
CC351 00D 257 2015 903 CS77B1A100MT
CC352,353 nsp 00D 257 0510 918 CK73B1H332KT +1608
CC354 nsp 00D 257 0508 917 CC73CH1H471JT +1608 CAPACITOR
CC355 00D 257 2015 903 CS77B1A100MT
CC356-358 nsp 00D 257 0508 917 CC73CH1H471JT +1608 CAPACITOR
CC365,366 nsp 00D 257 0510 918 CK73B1H332KT +1608
CC369,370 nsp 00D 257 0508 917 CC73CH1H471JT +1608 CAPACITOR
CC373,374 nsp 00D 257 0508 917 CC73CH1H471JT +1608 CAPACITOR
CC471 00D 257 2015 903 CS77B1A100MT
CC472-474 nsp 00D 257 0516 954 CK73B1E104KT +1608
CC475 00D 257 2015 903 CS77B1A100MT
CC476 nsp 00D 257 0516 954 CK73B1E104KT +1608
CC477-479 nsp 00D 257 0509 929 CK73B1H102KT +1608
CC480,481 00D 257 2015 903 CS77B1A100MT
CC482 nsp 00D 257 0509 929 CK73B1H102KT +1608
CC483,484 nsp 00D 257 0516 954 CK73B1E104KT +1608
Ref. No. nsp Part No. Part Name Remarks Q'ty New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-4306 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	102 dB
Dynamic power per channel (4 Ohm)	220 W
Dynamic power per channel (8 Ohm)	150 W
Power output per channel (1KHz@6 Ohm)	170 W
Power output per channel (20-20KHz@8 Ohm)	130 W
HDMI in	3
Line-in	Yes
Composite video in	7
USB ports quantity	1
Digital audio coaxial in	2
Digital audio optical in	5
Headphone connectivity	3.5 mm
Speakers connectivity type	RCA
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	1 W
Power consumption (typical)	570 W
3D	-
Optical drive included	No
Product color	Silver
Audio decoders	DTS 96/24, DTS Neo:6, DTS-ES, Dolby Digital, Dolby Digital EX, Dolby Pro Logic IIx
Apple docking compatibility	iPod

Weight and Dimensions

Depth	429 mm
Width	434 mm
Height	171 mm
Weight	18500 g
