Denon AVR-4306 Service Manual

74
AVR-4306/AVC-4320
CC485 00D 257 2015 903 CS77B1A100MT
CC486,487 nsp 00D 257 0509 929 CK73B1H102KT +1608
CC488-490 nsp 00D 257 0516 954 CK73B1E104KT +1608
CC492-496 nsp 00D 257 0516 954 CK73B1E104KT +1608
CC601,602 nsp 00D 257 0506 977 CC73CH1H121JT +1608
CC603-606 nsp 00D 257 0516 954 CK73B1E104KT +1608
CC607-609 00D 254 4464 906 CE67C0J101MT +REF
CC610 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
CC612 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
CC614 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
CC616 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
CC624 00D 254 4601 934 CE67W0J101MT(P.CAP) +REF
CC625 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
CC626 00D 254 4601 934 CE67W0J101MT(P.CAP) +REF
CC627 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
CC628,629 00D 254 4464 906 CE67C0J101MT +REF
CC630 00D 254 4464 906 CE67C0J101MT +REF
CC631 00D 254 4464 951 CE67C0J220MT(MV-B) +REF
CC632 00D 254 4464 906 CE67C0J101MT +REF
CC633 00D 254 4464 951 CE67C0J220MT(MV-B) +REF
CC634 00D 254 4464 906 CE67C0J101MT +REF
CC635 00D 254 4464 951 CE67C0J220MT(MV-B) +REF
CC636 00D 254 4655 977 CE67C0J102MT (RV) +REF
CC638 00D 254 4464 906 CE67C0J101MT +REF
CC640 00D 254 4464 906 CE67C0J101MT +REF
CC641 nsp 00D 257 0516 954 CK73B1E104KT +1608
CC642 00D 254 4464 906 CE67C0J101MT +REF
CC643-645 00D 254 4572 908 CE67C1C100MT(MV-B) +REF
CC646 00D 254 4464 951 CE67C0J220MT(MV-B) +REF
CC647 00D 254 4572 908 CE67C1C100MT(MV-B) +REF
CC649-651 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
CC652 nsp 00D 257 0516 954 CK73B1E104KT +1608
CC801 nsp 00D 257 0516 954 CK73B1E104KT +1608
CC802 nsp 00D 257 0509 929 CK73B1H102KT +1608
CC803 nsp 00D 257 0516 954 CK73B1E104KT +1608
OTHERS PARTS GROUP
CW101 nsp 00D 205 1326 003 10P SOCKET(9120)
CW112,113 nsp 00D 205 1326 016 11P SOCKET(9120)
CW118 nsp 00D 205 0885 066 11P CON.SOCKET TUC-P
CW137 nsp 00D 205 1326 032 13P SOCKET(9120)
CW159 nsp 00D 205 1326 058 15P SOCKET(9120)
CW401 00D 205 1379 908 40P PLUG(9841B) *
CW968 nsp 00D 205 1325 062 6P SOCKET(9120)
CX152 00D 205 1343 950 7P FFC BASE(9610SC)
CX252 00D 205 1343 905 11P FFC BASE(9610SCA
CX401 00D 205 1380 900 40P SOCKET(9830S) *
CX710 nsp 00D 205 1154 903 10P ZH-ZR CON.BASE-T
CX888 nsp 00D 205 0863 936 3P PH CON.BASE(L) +REF
CX891 nsp 00D 205 1154 990 9P ZH-ZR CON.BASE-T
CX933 00D 205 1343 976 13P FFC BASE(9610SC) *
CX941 nsp 00D 205 1154 945 4P ZH-ZR CON.BASE-T
CX957 nsp 00D 205 1072 920 5P PH CON BASE(TAPE) +REF
CX958 nsp 00D 205 1072 904 3P PH CON.BASE(TAPE) +REF
CY032 nsp 00D 205 1154 932 3P ZH-ZR CON.BASE-T
CY043 nsp 00D 205 1072 917 4P PH CON BASE(TAPE) +REF
CY045 nsp 00D 205 1072 917 4P PH CON BASE(TAPE) +REF
CY061 nsp 00D 205 1072 946 6P PH CON.BASE +REF
CY081 nsp 00D 205 1154 987 8P ZH-ZR CON.BASE(T) +REF
CY110 00D 205 1257 949 11P FFC BASE (9610SD
CY181 00D 205 1378 909 18P FFC BASE(9610SD)
CY710 nsp 00D 205 1154 903 10P ZH-ZR CON.BASE-T
CY777 nsp 00D 205 1154 974 7P ZH-ZR CON.BASE-T
Ref. No. nsp Part No. Part Name Remarks Q'ty New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-4306 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	102 dB
Dynamic power per channel (4 Ohm)	220 W
Dynamic power per channel (8 Ohm)	150 W
Power output per channel (1KHz@6 Ohm)	170 W
Power output per channel (20-20KHz@8 Ohm)	130 W
HDMI in	3
Line-in	Yes
Composite video in	7
USB ports quantity	1
Digital audio coaxial in	2
Digital audio optical in	5
Headphone connectivity	3.5 mm
Speakers connectivity type	RCA
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	1 W
Power consumption (typical)	570 W
3D	-
Optical drive included	No
Product color	Silver
Audio decoders	DTS 96/24, DTS Neo:6, DTS-ES, Dolby Digital, Dolby Digital EX, Dolby Pro Logic IIx
Apple docking compatibility	iPod

Weight and Dimensions

Depth	429 mm
Width	434 mm
Height	171 mm
Weight	18500 g
