Denon AVR-4306 Service Manual

75
AVR-4306/AVC-4320
CY891 nsp 00D 205 1154 990 9P ZH-ZR CON.BASE-T
FB151 00D 235 0181 907 ZBFS5105-PT
FB305 nsp 00D 247 2018 903 RM73B--0R0KT +1608
FB311 nsp 00D 247 2018 903 RM73B--0R0KT +1608
FB313 nsp 00D 247 2018 903 RM73B--0R0KT +1608
FB315 nsp 00D 247 2018 903 RM73B--0R0KT +1608
FB317 nsp 00D 247 2018 903 RM73B--0R0KT +1608
FB321,322 nsp 00D 247 0018 905 RM73B--0R0KT +2125
FB901 00D 235 0130 903 CHIP EMIFIL(11A121) +1608
FB904-908 00D 235 0130 903 CHIP EMIFIL(11A121) +1608
JK202 00D 204 8719 005 19P HDMI CONNECTOR
JK401,402 00D 204 8719 005 19P HDMI CONNECTOR
JK471 00D 204 8719 005 19P HDMI CONNECTOR
JK802 00D 205 1362 009 XM/DT BUS CONNECTOR
JK901 00D 205 1333 009 8P MODULAR
L201-204 00D 235 0125 905 INDUCTOR(FLC32C220K)+3216
L401,402 00D 235 0125 905 INDUCTOR(FLC32C220K)+3216
L404,405 00D 235 0125 905 INDUCTOR(FLC32C220K)+3216
L471-473 00D 235 0125 905 INDUCTOR(FLC32C220K)+3216
L604 nsp 00D 247 1018 904 RM73B20R0KT +3216
L607 nsp 00D 247 1018 904 RM73B20R0KT +3216
L751 00D 235 0125 905 INDUCTOR(FLC32C220K)+3216
RL202 00D 214 0238 905 RELAY(UB2-12NUN-L1)
RL401,402 00D 214 0238 905 RELAY(UB2-12NUN-L1)
S501 00D 212 4807 909 TACT SW(SKQDAA) +REF
W801 nsp 00D 412 5289 003 IPOD BRACKET
X201 00D 399 1039 909 FCX-03(28.322MHZ)
X251 00D 399 1038 900 FCX-03(12MHZ)
X401 00D 399 1039 909 FCX-03(28.322MHZ)
X601 00D 399 1000 909 FCX-03(28.63636MHZ)
X751 00D 399 0864 900 XTAL(13.5MHZ) +REF
X901 00D 399 1047 904 FCX-03(25MHZ) *
nsp 00D 461 0415 007 RUBBER SHEET
Ref. No. nsp Part No. Part Name Remarks Q'ty New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-4306 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	102 dB
Dynamic power per channel (4 Ohm)	220 W
Dynamic power per channel (8 Ohm)	150 W
Power output per channel (1KHz@6 Ohm)	170 W
Power output per channel (20-20KHz@8 Ohm)	130 W
HDMI in	3
Line-in	Yes
Composite video in	7
USB ports quantity	1
Digital audio coaxial in	2
Digital audio optical in	5
Headphone connectivity	3.5 mm
Speakers connectivity type	RCA
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	1 W
Power consumption (typical)	570 W
3D	-
Optical drive included	No
Product color	Silver
Audio decoders	DTS 96/24, DTS Neo:6, DTS-ES, Dolby Digital, Dolby Digital EX, Dolby Pro Logic IIx
Apple docking compatibility	iPod

Weight and Dimensions

Depth	429 mm
Width	434 mm
Height	171 mm
Weight	18500 g
