AVR-4306/AVC-4320

00D1U-3700E MAIN CPU P.W.B. UNIT ASS'Y

Ref. No. nsp Part No. Part Name Remarks Q'ty New

SEMICONDUCTORS GROUP

IC501,502 00D 262 2375 904 IC, TC4094BF(TP1) +C

IC504 00D 262 2375 904 IC, TC4094BF(TP1) +C

IC506 00D GEN 8062 MAIN CPU SUB ASSY M30879FLFP

IC508 00D 262 2375 904 IC, TC4094BF(TP1) +C

IC510 00D 262 3576 906 TC74VHCT244AF *

IC511 00D 262 3563 906 TC7SH08F

IC801 00D 263 0896 909 NJM2068MD-TE1 +C

IC901 00D 262 2213 901 TC74HC151AF +C

IC902,903 00D 262 3564 905 TC74VHCU04F

IC904 00D 262 3561 908 TC74VHC14F

IC905,906 00D 262 2213 901 TC74HC151AF +C

IC907-910 00D 262 3387 001 TORX142(F)

IC911,912 00D 262 3386 002 TOTX142(F)

IC913 00D 262 3561 908 TC74VHC14F

IC915 00D 263 1100 021 KIA7812API

TR107 00D 269 0192 902 KRC102S-RTK(10K-10K) +C

TR108,109 00D 271 0312 905 2SA/KTA1504SGR-RTK +C

TR110 00D 269 0192 902 KRC102S-RTK(10K-10K) +C

TR501 00D 269 0192 902 KRC102S-RTK(10K-10K) +C

TR502 00D 271 0326 904 2SA1954(B)-TE85L

TR503,504 00D 269 0192 902 KRC102S-RTK(10K-10K) +C

TR505 00D 269 0193 901 KRC104S-RTK(47K-47K) +C

TR506 00D 269 0192 902 KRC102S-RTK(10K-10K) +C

TR507 00D 269 0191 903 KRA104S-RTK(47K-47K) +C

TR508 00D 269 0193 901 KRC104S-RTK(47K-47K) +C

TR509 00D 271 0326 904 2SA1954(B)-TE85L

TR510 00D 269 0192 902 KRC102S-RTK(10K-10K) +C

TR513 00D 271 0326 904 2SA1954(B)-TE85L

TR517 00D 271 0326 904 2SA1954(B)-TE85L

TR518 00D 269 0192 902 KRC102S-RTK(10K-10K) +C

TR519 00D 269 0193 901 KRC104S-RTK(47K-47K) +C

TR520 00D 269 0191 903 KRA104S-RTK(47K-47K) +C

TR521 00D 269 0193 901 KRC104S-RTK(47K-47K) +C

TR523 00D 269 0193 901 KRC104S-RTK(47K-47K) +C

TR524 00D 273 0464 901 KTC3875SGR-RTK +C

TR801-824 00D 273 0460 905 KTC2875B-RTK +C

TR825-832 00D 269 0184 907 KRA102S-RTK +C

TR833 00D 269 0192 902 KRC102S-RTK(10K-10K) +C

TR834 00D 269 0184 907 KRA102S-RTK +C

TR902,903 00D 269 0192 902 KRC102S-RTK(10K-10K) +C

TR904 00D 269 0086 908 DTA114TKT96 +C

TR905,906 00D 269 0066 902 DTC323TKT96 +C

D501,502 00D 276 0704 903 1SR35-400A(T93X)

D503 00D 276 0794 900 KDS160 +2125

D504 00D 276 0454 910 HZS3C-2TD

D505 00D 276 0794 900 KDS160 +2125

D506 00D 276 0454 910 HZS3C-2TD

D801-803 00D 276 0704 903 1SR35-400A(T93X)

D804 00D 276 0683 901 UDZS5.6B-TE17 +C

D805-808 00D 276 0794 900 KDS160 +2125

D901,902 00D 276 0738 908 KDS226-RTK(A-K) +C

RESISTORS GROUP

R579 00D 241 2387 908 RD14B2E010JNBST

R588 00D 241 2387 908 RD14B2E010JNBST

RR837 00D 244 2055 996 RS14B3A122JNBST(S)

RR839,840 00D 244 2055 996 RS14B3A122JNBST(S)
