Denon AVR-4306 Service Manual

77
AVR-4306/AVC-4320
CAPACITORS GROUP
C501 nsp 00D 257 0516 954 CK73B1E104KT +1608
C502,503 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C504 nsp 00D 257 0509 929 CK73B1H102KT +1608
C505 nsp 00D 257 0516 954 CK73B1E104KT +1608
C507 00D 254 4666 005 CE04W0H105ZC(FG)
C508 00D 254 4573 981 CE04W1H100MT(RE3)
C509,510 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C540 00D 254 4574 906 CE04W1H330MT(RE3)
C545 nsp 00D 257 0509 929 CK73B1H102KT +1608
C546 00D 254 4533 934 CE04W0J221MT SMG/RE3
C547,548 nsp 00D 257 0502 971 CC73CH1H5R0CT +1608
C551 nsp 00D 257 0509 929 CK73B1H102KT +1608
C555 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C564 nsp 00D 257 0516 954 CK73B1E104KT +1608
C567 00D 254 4574 906 CE04W1H330MT(RE3)
C570 00D 254 4569 924 CE04W1E101MT(RE3)
C571 nsp 00D 257 0516 954 CK73B1E104KT +1608
C574 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C575 00D 254 4573 978 CE04W1H4R7MT(RE3)
C581 00D 255 1279 951 CQ93M1H104JT(B)
C801-804 00D 254 4573 994 CE04W1H220MT(RE3)
C807-810 00D 254 4573 994 CE04W1H220MT(RE3)
C813-816 00D 254 4573 994 CE04W1H220MT(RE3)
C819-822 00D 254 4573 994 CE04W1H220MT(RE3)
C825-828 00D 254 4573 994 CE04W1H220MT(RE3)
C831-834 00D 254 4573 994 CE04W1H220MT(RE3)
C837 00D 254 4573 949 CE04W1H010MT(RE3)
C838,839 nsp 00D 257 0516 954 CK73B1E104KT +1608
C840 00D 254 4573 949 CE04W1H010MT(RE3)
C841-843 nsp 00D 257 0516 954 CK73B1E104KT +1608
C844-851 nsp 00D 257 0507 976 CC73CH1H331JT +1608
C852-855 nsp 00D 257 0516 954 CK73B1E104KT +1608
C856 00D 254 4573 949 CE04W1H010MT(RE3)
C857-859 00D 254 4573 907 CE04W1H0R1MT(RE3)
C860 00D 254 4573 981 CE04W1H100MT(RE3)
C861-864 00D 254 4573 907 CE04W1H0R1MT(RE3)
C865 00D 254 4574 922 CE04W1H101MT(RE3)
C866 00D 254 4573 907 CE04W1H0R1MT(RE3)
C867-870 00D 254 4577 903 CE04W1C100MT(RE3)
C871-874 nsp 00D 257 0509 929 CK73B1H102KT +1608
C875-878 nsp 00D 257 0506 977 CC73CH1H121JT +1608
C879,880 nsp 00D 257 0516 954 CK73B1E104KT +1608
C881,882 00D 254 4577 903 CE04W1C100MT(RE3)
C901,902 nsp 00D 247 2018 903 RM73B--0R0KT +1608
C905-910 nsp 00D 257 0516 954 CK73B1E104KT +1608
C911-913 00D 254 4574 906 CE04W1H330MT(RE3)
C914-917 nsp 00D 257 0516 954 CK73B1E104KT +1608
C918-923 00D 254 4573 978 CE04W1H4R7MT(RE3)
C924,925 nsp 00D 257 0516 954 CK73B1E104KT +1608
C926 00D 254 4573 978 CE04W1H4R7MT(RE3)
C929-931 nsp 00D 257 0516 954 CK73B1E104KT +1608
C939,940 00D 254 4573 949 CE04W1H010MT(RE3)
C942 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C944,945 nsp 00D 257 0509 929 CK73B1H102KT +1608
C947-949 nsp 00D 257 0509 929 CK73B1H102KT +1608
C950 00D 254 4573 981 CE04W1H100MT(RE3)
C952,953 nsp 00D 257 0509 929 CK73B1H102KT +1608
C955 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
OTHERS PARTS GROUP
CW052 nsp 00D 205 0343 058 5P CONN.BASE(KR-PH)
CW053 nsp 00D 205 0321 054 5P CONNE.BASE (RED)
CW114 nsp 00D 205 0885 066 11P CON.SOCKET TUC-P
CW119 nsp 00D 205 0885 066 11P CON.SOCKET TUC-P
Ref. No. nsp Part No. Part Name Remarks Q'ty New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-4306 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	102 dB
Dynamic power per channel (4 Ohm)	220 W
Dynamic power per channel (8 Ohm)	150 W
Power output per channel (1KHz@6 Ohm)	170 W
Power output per channel (20-20KHz@8 Ohm)	130 W
HDMI in	3
Line-in	Yes
Composite video in	7
USB ports quantity	1
Digital audio coaxial in	2
Digital audio optical in	5
Headphone connectivity	3.5 mm
Speakers connectivity type	RCA
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	1 W
Power consumption (typical)	570 W
3D	-
Optical drive included	No
Product color	Silver
Audio decoders	DTS 96/24, DTS Neo:6, DTS-ES, Dolby Digital, Dolby Digital EX, Dolby Pro Logic IIx
Apple docking compatibility	iPod

Weight and Dimensions

Depth	429 mm
Width	434 mm
Height	171 mm
Weight	18500 g
