Denon AVR-4306 Service Manual

78
AVR-4306/AVC-4320
CW141 nsp 00D 205 0885 011 14P CON.SOCKET TUC-P
CW145 nsp 00D 205 1229 029 14P FJ CONN.PLUG
CW151,152 nsp 00D 205 0885 040 15P CON.SOCKET TUC-P
CW157 nsp 00D 205 0885 040 15P CON.SOCKET TUC-P
CW161 nsp 00D 205 0942 051 16P CON.SOCKET TUC-P
CW912,913 nsp 00D 205 1249 038 11P JE CON.BASE
CW914 nsp 00D 205 1229 016 11P FJ CONN.PLUG
CW967 nsp 00D 205 0942 019 6P CON.SOCKET(TUC-P
CW973 nsp 00D 205 0942 022 7P CON.SOCKET(TUC-P
CX031 nsp 00D 205 0321 038 3P CONNE.BASE(RED)
CX033 nsp 00D 205 0321 038 3P CONNE.BASE(RED)
CX066 nsp 00D 205 0343 061 6P CONN.BASE(KR-PH)
CX081 nsp 00D 205 0343 087 8P CONN.BASE(KR-PH)
CX101 nsp 00D 205 1324 005 10P PIN HEADER(9120)
CX112,113 nsp 00D 205 1324 018 11P PIN HEADER(9120)
CX114-116 nsp 00D 205 0884 067 11P CON.BASE TUC-P
CX118 nsp 00D 205 0884 067 11P CON.BASE TUC-P
CX132 nsp 00D 205 1091 037 13P CON BASE TWG-P
CX133 nsp 00D 205 0943 005 13P CON.BASE(TUC-P)
CX137 nsp 00D 205 1324 034 13P PIN HEADER(9120)
CX141 nsp 00D 205 0884 012 14P CON.BASE TUC-P
CX150 00D 205 0736 076 15P FFC CON.BASE
CX154 nsp 00D 205 0884 041 15P CON.BASE TUC-P
CX159 nsp 00D 205 1324 050 15P PIN HEADER(9120)
CX161,162 nsp 00D 205 0943 050 16P CON.BASE TUC-P
CX177 00D 205 0736 047 17P FFC CON.BASE
CX178 00D 205 1100 038 17P FFC BASE(P=1)
CX251,252 00D 205 0736 089 25P FFC CON.BASE
CX777 nsp 00D 205 0762 079 7P ZR CON BASE
CX931 nsp 00D 205 0543 036 3P CONNE.BASE(YEL)
CX951 nsp 00D 205 0884 009 5P CON.BASE TUC-P
CX967 nsp 00D 205 0943 018 6P CON.BASE(TUC-P)
CX968 nsp 00D 205 1323 064 6P PIN HEADER(9120)
CX975 nsp 00D 205 1091 011 7P CON BASE TWG-P
CY033 nsp 00D 205 0321 038 3P CONNE.BASE(RED)
CY034 nsp 00D 205 0406 034 3P CON BASE(KR-PH)
CY052 nsp 00D 205 0343 058 5P CONN.BASE(KR-PH)
CY066 nsp 00D 205 0343 061 6P CONN.BASE(KR-PH)
CY171 00D 205 0736 047 17P FFC CON.BASE
CY612 nsp 00D 205 0323 036 3P CONNE.BASE(BLK)
CY931 nsp 00D 205 0543 036 3P CONNE.BASE(YEL)
CY932 nsp 00D 205 0343 032 3P CONN.BASE(KR-PH)
JK801-805 00D 204 8723 004 4P PIN JACK(NI)
JK901 00D 204 8658 001 2P PIN JACK(C-TYPE)
X501 00D 399 0594 005 X'TAL(30MHZ)
-1P WIRE
-1P WIRE
-1P WIRE
-1P WIRE
00D 276 0833 900 ESD PROTECTOR(6802)
Ref. No. nsp Part No. Part Name Remarks Q'ty New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-4306 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	102 dB
Dynamic power per channel (4 Ohm)	220 W
Dynamic power per channel (8 Ohm)	150 W
Power output per channel (1KHz@6 Ohm)	170 W
Power output per channel (20-20KHz@8 Ohm)	130 W
HDMI in	3
Line-in	Yes
Composite video in	7
USB ports quantity	1
Digital audio coaxial in	2
Digital audio optical in	5
Headphone connectivity	3.5 mm
Speakers connectivity type	RCA
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	1 W
Power consumption (typical)	570 W
3D	-
Optical drive included	No
Product color	Silver
Audio decoders	DTS 96/24, DTS Neo:6, DTS-ES, Dolby Digital, Dolby Digital EX, Dolby Pro Logic IIx
Apple docking compatibility	iPod

Weight and Dimensions

Depth	429 mm
Width	434 mm
Height	171 mm
Weight	18500 g
