Denon AVR-4306 Service Manual

80
AVR-4306/AVC-4320
R513,514 00D 244 2671 901 RS14B3D100JNBST(S)
R517,518 00D 244 2052 960 RS14B3A221JNBST(S)
R521,522 00D 244 2052 960 RS14B3A221JNBST(S)
R527,528 00D 244 2682 945 RS14B3D2R2JNBST(S)
R529,530 00D 244 2671 901 RS14B3D100JNBST(S)
R531,532 00D 243 2039 032 RW99=3H0R1K
R535 00D 244 2051 961 RS14B3A101JNBST(S)
R536 00D 241 2387 940 RD14B2E4R7JNBST
R609,610 00D 244 2050 920 RS14B3A121JNBST(S)
R624 00D 242 2009 001 RC05GF2H225K(UL)
VR101,102 00D 211 6131 939 V06PB331T
VR201 00D 211 6131 939 V06PB331T
VR301,302 00D 211 6131 939 V06PB331T
VR401,402 00D 211 6131 939 V06PB331T
CAPACITORS GROUP
C101,102 00D 254 4586 949 CE04W2A100MT(RE3)
C103-106 00D 254 4586 936 CE04W2A4R7MT(RE3)
C201 00D 254 4586 949 CE04W2A100MT(RE3)
C203 00D 254 4586 936 CE04W2A4R7MT(RE3)
C205 00D 254 4586 936 CE04W2A4R7MT(RE3)
C301,302 00D 254 4586 949 CE04W2A100MT(RE3)
C303-306 00D 254 4586 936 CE04W2A4R7MT(RE3)
C401,402 00D 254 4586 949 CE04W2A100MT(RE3)
C403-406 00D 254 4586 936 CE04W2A4R7MT(RE3)
C501,502 00D 255 1279 919 CQ93M1H473JT(B)
C503,504 00D 255 1264 982 CQ93M1H472JT(B)
C505,506 nsp 00D 257 0509 929 CK73B1H102KT +1608
C507 00D 255 1279 919 CQ93M1H473JT(B)
C508 00D 255 1264 982 CQ93M1H472JT(B)
C509 nsp 00D 257 0509 929 CK73B1H102KT +1608
C510,511 00D 255 1279 919 CQ93M1H473JT(B)
C512,513 00D 255 1264 982 CQ93M1H472JT(B)
C514,515 nsp 00D 257 0509 929 CK73B1H102KT +1608
C516,517 00D 255 1279 919 CQ93M1H473JT(B)
C518-521 00D 255 1264 982 CQ93M1H472JT(B)
C522-525 nsp 00D 257 0509 929 CK73B1H102KT +1608
C526 00D 254 4573 949 CE04W1H010MT(RE3)
C528,529 00D 254 6259 009 CE68W==183M(DL) *
C530-532 00D 256 1064 907 CF93A2E334KT(B)L=16
C533 00D 254 4587 715 CE04W2A101MC(RE3)
! C601 00D 253 8022 707 CK45F2EAC103MC
C603 00D 254 4573 981 CE04W1H100MT(RE3)
C605 00D 254 4760 736 CE04W1E682MC(SMQ)
C606 00D 254 4573 949 CE04W1H010MT(RE3)
C607 00D 255 1279 951 CQ93M1H104JT(B)
C616 00D 254 4573 981 CE04W1H100MT(RE3)
C617 00D 254 4573 949 CE04W1H010MT(RE3)
C622 00D 254 4764 703 CE04W1C223MCP35(SMQ)
C623 00D 254 4573 949 CE04W1H010MT(RE3)
C624 00D 255 1279 951 CQ93M1H104JT(B)
! C625 00D 253 8022 707 CK45F2EAC103MC
C653 00D 254 4523 724 CE04W1V472MC SMG/RE3
C654 00D 254 4573 981 CE04W1H100MT(RE3)
C655 00D 254 4573 949 CE04W1H010MT(RE3)
C656 00D 255 1279 951 CQ93M1H104JT(B)
OTHERS PARTS GROUP
! AC601 00D 203 3976 002 AC OUTLET(2P)
CW042 nsp 00D 203 6633 009 4P KR-DA CON.CORD
CW731 nsp 00D 203 5345 039 3P EH-SCN CON.CORD
CW972 nsp 00D 205 0942 022 7P CON.SOCKET(TUC-P
Ref. No. nsp Part No. Part Name Remarks Q'ty New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-4306 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	102 dB
Dynamic power per channel (4 Ohm)	220 W
Dynamic power per channel (8 Ohm)	150 W
Power output per channel (1KHz@6 Ohm)	170 W
Power output per channel (20-20KHz@8 Ohm)	130 W
HDMI in	3
Line-in	Yes
Composite video in	7
USB ports quantity	1
Digital audio coaxial in	2
Digital audio optical in	5
Headphone connectivity	3.5 mm
Speakers connectivity type	RCA
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	1 W
Power consumption (typical)	570 W
3D	-
Optical drive included	No
Product color	Silver
Audio decoders	DTS 96/24, DTS Neo:6, DTS-ES, Dolby Digital, Dolby Digital EX, Dolby Pro Logic IIx
Apple docking compatibility	iPod

Weight and Dimensions

Depth	429 mm
Width	434 mm
Height	171 mm
Weight	18500 g
