Denon AVR-4306 Service Manual

81
AVR-4306/AVC-4320
CW978 nsp 00D 205 0942 022 7P CON.SOCKET(TUC-P
CX022 nsp 00D 205 0768 002 2P VH CON.BASE (BLK)
CX023 nsp 00D 205 0581 001 2P VH CONNECTOR BASE
CX024 nsp 00D 205 0581 085 2P VH CONNECTOR BASE
CX045 nsp 00D 205 0406 047 4P CON BASE(KR-PH)
CX046 nsp 00D 205 0233 045 4P EH CONNECTOR BASE
CX055 nsp 00D 205 0653 052 5P VH CONNECTOR BASE
CX091 nsp 00D 205 0884 038 9P CON.BASE TUC-P
CX111 nsp 00D 205 1091 024 11P CON BASE TWG-P
CX131 nsp 00D 205 1091 037 13P CON BASE TWG-P
CX521 nsp 00D 205 1093 006 2P VH CONNECTOR BASA
CX611 nsp 00D 205 0296 037 3P EH CON BASE (YW)
CX612 nsp 00D 205 0323 036 3P CONNE.BASE(BLK)
CX731 nsp 00D 205 0233 032 3P EH CONNECTOR BASE
CX961-966 nsp 00D 205 0943 018 6P CON.BASE(TUC-P)
CX971,972 nsp 00D 205 0943 021 7P CON.BASE(TUC-P)
CX978 nsp 00D 205 0943 021 7P CON.BASE(TUC-P)
CY021 nsp 00D 205 0581 069 2P VH-VH CON BASE
! F1 00D 206 1086 003 FUSE 8A (UL/CSA/J)
! F8 00D 206 1046 014 FUSE 8A
! F17 00D 206 1039 063 FUSE 2.0A T
FF602 nsp 00D 202 0040 909 FUSE CLIP(TAPE)
FF603 nsp 00D EP- 5870 FUSE HOLDER
FF606 nsp 00D 202 0040 909 FUSE CLIP(TAPE)
FH602 nsp 00D 202 0040 909 FUSE CLIP(TAPE)
FH603 nsp 00D EP- 5870 FUSE HOLDER
FH606 nsp 00D 202 0040 909 FUSE CLIP(TAPE)
JK501 00D 205 1252 009 4P SP TERMINAL(V0)
JK502 00D 205 1251 000 6P SP TERMINAL(V0)
JK503 00D 205 1250 001 8P SP TERMINAL(V0)
L501-507 00D 235 0191 007 INDUCTOR(1MH)
RL501 00D 214 0217 007 RELAY(DS24D2)
RL502 00D 214 0223 004 RELAY(EC2-24N35)
RL503-506 00D 214 0217 007 RELAY(DS24D2)
! RL601,602 00D 214 0221 006 RELAY TV-8
ST601 - STYLE PIN
! T602 00D 233 6524 009 MINI TRANS(3806E3)
TP101 nsp 00D 205 0190 065 6P NH CONNECTOR BASE
TP301 nsp 00D 205 0190 081 8P NH CONNECTOR BASE
W311 - 1P WIRE
W701 nsp 00D 205 1034 007 M3 SCREW TERMINAL
W703 nsp 00D 205 1034 007 M3 SCREW TERMINAL
-1P WIRE
-RADIATOR
-RADIATOR
nsp 00D 473 7005 002 3X10 CBTS (S)-Z
nsp 00D 477 0153 018 3X16 CPTS(B) SW W
Ref. No. nsp Part No. Part Name Remarks Q'ty New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-4306 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	102 dB
Dynamic power per channel (4 Ohm)	220 W
Dynamic power per channel (8 Ohm)	150 W
Power output per channel (1KHz@6 Ohm)	170 W
Power output per channel (20-20KHz@8 Ohm)	130 W
HDMI in	3
Line-in	Yes
Composite video in	7
USB ports quantity	1
Digital audio coaxial in	2
Digital audio optical in	5
Headphone connectivity	3.5 mm
Speakers connectivity type	RCA
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	1 W
Power consumption (typical)	570 W
3D	-
Optical drive included	No
Product color	Silver
Audio decoders	DTS 96/24, DTS Neo:6, DTS-ES, Dolby Digital, Dolby Digital EX, Dolby Pro Logic IIx
Apple docking compatibility	iPod

Weight and Dimensions

Depth	429 mm
Width	434 mm
Height	171 mm
Weight	18500 g
