Denon AVR-4306 Service Manual

82
AVR-4306/AVC-4320
00D1U-3702E P.SUPPLY P.W.B. UNIT ASS'Y
Ref. No. nsp Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC601 00D 263 1048 002 BA033T
IC602 00D 263 1092 003 BA05T
IC603 00D 263 0554 005 IC, NJM7905FA
IC604 00D 263 1100 047 KIA7820API
IC605 00D 263 1100 005 KIA7805API
IC606,607 00D 263 1048 002 BA033T
IC608 00D 279 0034 067 PTH9M04BB222TS2F333
IC610 00D 263 1092 003 BA05T
IC832 00D 263 1163 000 KIA78R09PI
TR107-110 00D 271 0301 903 2SA/KTA1268BL-AT
TR111,112 00D 273 0471 907 KTC3206Y-AT
TR113,114 00D 271 0314 903 KTA1024Y-AT
TR115,116 00D 273 0471 907 KTC3206Y-AT
TR207 00D 271 0301 903 2SA/KTA1268BL-AT
TR209 00D 271 0301 903 2SA/KTA1268BL-AT
TR211 00D 273 0471 907 KTC3206Y-AT
TR213 00D 271 0314 903 KTA1024Y-AT
TR215 00D 273 0471 907 KTC3206Y-AT
TR307-310 00D 271 0301 903 2SA/KTA1268BL-AT
TR311,312 00D 273 0471 907 KTC3206Y-AT
TR313,314 00D 271 0314 903 KTA1024Y-AT
TR315,316 00D 273 0471 907 KTC3206Y-AT
TR407-410 00D 271 0301 903 2SA/KTA1268BL-AT
TR411,412 00D 273 0471 907 KTC3206Y-AT
TR413,414 00D 271 0314 903 KTA1024Y-AT
TR415,416 00D 273 0471 907 KTC3206Y-AT
TR601 00D 271 0313 904 KTA1281Y-AT
TR602 00D 269 0206 908 KRC102M-AT(10K-10K)
TR603 00D 272 0158 007 2SB/KTB778(R/O)
TR604,605 00D 271 0313 904 KTA1281Y-AT
TR606 00D 273 0469 906 2SC/KTC3209Y-AT
TR607 00D 269 0206 908 KRC102M-AT(10K-10K)
TR608 00D 271 0311 906 2SA/KTA1267GR-AT
TR609 00D 269 0206 908 KRC102M-AT(10K-10K)
TR610 00D 271 0313 904 KTA1281Y-AT
TR611 00D 269 0206 908 KRC102M-AT(10K-10K)
TR613 00D 274 0198 005 2SD/KTD998(R/O)
TR614 00D 272 0158 007 2SB/KTB778(R/O)
TR615 00D 273 0468 907 2SC/KTC3199GR-AT
TR616 00D 271 0311 906 2SA/KTA1267GR-AT
TR619 00D 272 0158 007 2SB/KTB778(R/O)
TR620 00D 271 0313 904 KTA1281Y-AT
TR621 00D 273 0468 907 2SC/KTC3199GR-AT
TR622 00D 272 0158 007 2SB/KTB778(R/O)
TR623 00D 274 0198 005 2SD/KTD998(R/O)
TR625 00D 269 0206 908 KRC102M-AT(10K-10K)
TR627 00D 272 0158 007 2SB/KTB778(R/O)
TR628 00D 271 0313 904 KTA1281Y-AT
TR629 00D 269 0206 908 KRC102M-AT(10K-10K)
TR701 00D 271 0301 903 2SA/KTA1268BL-AT
TR702,703 00D 273 0464 901 KTC3875SGR-RTK +C
TR704 00D 271 0312 905 2SA/KTA1504SGR-RTK +C
TR705,706 00D 273 0464 901 KTC3875SGR-RTK +C
TR707 00D 271 0312 905 2SA/KTA1504SGR-RTK +C
TR708,709 00D 273 0464 901 KTC3875SGR-RTK +C
TR710 00D 271 0312 905 2SA/KTA1504SGR-RTK +C
TR711,712 00D 273 0464 901 KTC3875SGR-RTK +C
D101-106 00D 276 0432 903 1SS270A TE (TAPE)
D201 00D 276 0432 903 1SS270A TE (TAPE)
D203 00D 276 0432 903 1SS270A TE (TAPE)
D205 00D 276 0432 903 1SS270A TE (TAPE)
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-4306 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	102 dB
Dynamic power per channel (4 Ohm)	220 W
Dynamic power per channel (8 Ohm)	150 W
Power output per channel (1KHz@6 Ohm)	170 W
Power output per channel (20-20KHz@8 Ohm)	130 W
HDMI in	3
Line-in	Yes
Composite video in	7
USB ports quantity	1
Digital audio coaxial in	2
Digital audio optical in	5
Headphone connectivity	3.5 mm
Speakers connectivity type	RCA
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	1 W
Power consumption (typical)	570 W
3D	-
Optical drive included	No
Product color	Silver
Audio decoders	DTS 96/24, DTS Neo:6, DTS-ES, Dolby Digital, Dolby Digital EX, Dolby Pro Logic IIx
Apple docking compatibility	iPod

Weight and Dimensions

Depth	429 mm
Width	434 mm
Height	171 mm
Weight	18500 g
