Denon AVR-4306 Service Manual

83
AVR-4306/AVC-4320
D301-306 00D 276 0432 903 1SS270A TE (TAPE)
D401-406 00D 276 0432 903 1SS270A TE (TAPE)
D603,604 00D 276 0723 900 RB721Q-40
D605 00D 276 0305 001 S4VB20
D606,607 00D 276 0432 903 1SS270A TE (TAPE)
D608 00D 276 0305 001 S4VB20
D609,610 00D 276 0704 903 1SR35-400A(T93X)
D611 00D 276 0432 903 1SS270A TE (TAPE)
D612 00D 276 0723 900 RB721Q-40
D613 00D 276 0637 902 MTZJ6.2AT77
D615 00D 276 0305 001 S4VB20
D616 00D 276 0637 902 MTZJ6.2AT77
D618 00D 276 0305 001 S4VB20
D619,620 00D 276 0432 903 1SS270A TE (TAPE)
D623 00D 276 0432 903 1SS270A TE (TAPE)
D624-627 00D 276 0704 903 1SR35-400A(T93X)
ZD601,602 00D 276 0477 926 HZS16-3TD
ZD603 00D 276 0474 903 HZS12B-1TD
ZD604,605 00D 276 0463 901 HZS6C-1TD
RESISTORS GROUP
R127,128 00D 241 2379 987 RD14B2E102JNBST
R133,134 00D 241 2379 987 RD14B2E102JNBST
R137,138 00D 244 2671 914 RS14B3D153JNBST(S)
R139,140 00D 241 2378 920 RD14B2E221JNBST
R141,142 00D 241 2378 946 RD14B2E271JNBST
R143,144 00D 241 2378 920 RD14B2E221JNBST
R227 00D 241 2379 987 RD14B2E102JNBST
R233 00D 241 2379 987 RD14B2E102JNBST
R237 00D 244 2671 914 RS14B3D153JNBST(S)
R239 00D 241 2378 920 RD14B2E221JNBST
R241 00D 241 2378 946 RD14B2E271JNBST
R243 00D 241 2378 920 RD14B2E221JNBST
R327,328 00D 241 2379 987 RD14B2E102JNBST
R333,334 00D 241 2379 987 RD14B2E102JNBST
R337,338 00D 244 2671 914 RS14B3D153JNBST(S)
R339,340 00D 241 2378 920 RD14B2E221JNBST
R341,342 00D 241 2378 946 RD14B2E271JNBST
R343,344 00D 241 2378 920 RD14B2E221JNBST
R427,428 00D 241 2379 987 RD14B2E102JNBST
R433,434 00D 241 2379 987 RD14B2E102JNBST
R437,438 00D 244 2671 914 RS14B3D153JNBST(S)
R439,440 00D 241 2378 920 RD14B2E221JNBST
R441,442 00D 241 2378 946 RD14B2E271JNBST
R443,444 00D 241 2378 920 RD14B2E221JNBST
R602 00D 241 2376 919 RD14B2E300JNBST
R618 00D 241 2376 919 RD14B2E300JNBST
R623,624 00D 241 2376 919 RD14B2E300JNBST
R625,626 00D 244 2050 959 RS14B3A271JNBST(S)
R629 00D 241 2376 919 RD14B2E300JNBST
R635,636 00D 244 2050 988 RS14B3A202JNBST(S)
CAPACITORS GROUP
C109,110 00D 254 4573 981 CE04W1H100MT(RE3)
C111,112 00D 255 1273 944 CQ93M1H221KT(B)
C113,114 00D 255 1273 986 CQ93M1H471JT(B)
C115,116 00D 255 1264 966 CQ93M1H332JT(B)
C117,118 00D 254 4579 707 CE04W1H221MC(RE3)
C119,120 00D 253 4552 909 CC45SL2H330JT
C121,122 00D 253 4550 901 CC45SL2H050CT
C123,124 00D 253 4551 900 CC45SL2H470JT
C125,126 00D 255 1275 942 CQ93M2A221KT(B)
C209 00D 254 4573 981 CE04W1H100MT(RE3)
Ref. No. nsp Part No. Part Name Remarks Q'ty New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-4306 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	102 dB
Dynamic power per channel (4 Ohm)	220 W
Dynamic power per channel (8 Ohm)	150 W
Power output per channel (1KHz@6 Ohm)	170 W
Power output per channel (20-20KHz@8 Ohm)	130 W
HDMI in	3
Line-in	Yes
Composite video in	7
USB ports quantity	1
Digital audio coaxial in	2
Digital audio optical in	5
Headphone connectivity	3.5 mm
Speakers connectivity type	RCA
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	1 W
Power consumption (typical)	570 W
3D	-
Optical drive included	No
Product color	Silver
Audio decoders	DTS 96/24, DTS Neo:6, DTS-ES, Dolby Digital, Dolby Digital EX, Dolby Pro Logic IIx
Apple docking compatibility	iPod

Weight and Dimensions

Depth	429 mm
Width	434 mm
Height	171 mm
Weight	18500 g
