Denon AVR-4306 Service Manual

84
AVR-4306/AVC-4320
C211 00D 255 1273 944 CQ93M1H221KT(B)
C213 00D 255 1273 986 CQ93M1H471JT(B)
C215 00D 255 1264 966 CQ93M1H332JT(B)
C217 00D 254 4579 707 CE04W1H221MC(RE3)
C219 00D 253 4552 909 CC45SL2H330JT
C221 00D 253 4550 901 CC45SL2H050CT
C223 00D 253 4551 900 CC45SL2H470JT
C225 00D 255 1275 942 CQ93M2A221KT(B)
C309,310 00D 254 4573 981 CE04W1H100MT(RE3)
C311,312 00D 255 1273 944 CQ93M1H221KT(B)
C313,314 00D 255 1273 986 CQ93M1H471JT(B)
C315,316 00D 255 1264 966 CQ93M1H332JT(B)
C317,318 00D 254 4579 707 CE04W1H221MC(RE3)
C319,320 00D 253 4552 909 CC45SL2H330JT
C321,322 00D 253 4550 901 CC45SL2H050CT
C323,324 00D 253 4551 900 CC45SL2H470JT
C325,326 00D 255 1275 942 CQ93M2A221KT(B)
C409,410 00D 254 4573 981 CE04W1H100MT(RE3)
C411,412 00D 255 1273 944 CQ93M1H221KT(B)
C413,414 00D 255 1273 986 CQ93M1H471JT(B)
C415,416 00D 255 1264 966 CQ93M1H332JT(B)
C417,418 00D 254 4579 707 CE04W1H221MC(RE3)
C419,420 00D 253 4552 909 CC45SL2H330JT
C421,422 00D 253 4550 901 CC45SL2H050CT
C423,424 00D 253 4551 900 CC45SL2H470JT
C425,426 00D 255 1275 942 CQ93M2A221KT(B)
C599 00D 254 4347 748 CE04W1H010MC(ARSA)
C601 00D 254 4577 945 CE04W1C101MT(RE3)
C602-606 00D 255 1279 951 CQ93M1H104JT(B)
C607 00D 254 4569 911 CE04W1E470MT(RE3)
C608 00D 254 4573 965 CE04W1H3R3MT(RE3)
C609 nsp 00D 257 0509 929 CK73B1H102KT +1608
C610 00D 254 4760 707 CE04W1E103MC(SMQ)
C611 00D 256 1042 903 CF93A2E104KT
C612 00D 254 4569 911 CE04W1E470MT(RE3)
C613-616 00D 254 4573 949 CE04W1H010MT(RE3)
C617,618 00D 254 4761 706 CE04W1C153MC(SMQ)
C619,620 00D 254 4573 949 CE04W1H010MT(RE3)
C621 00D 254 4573 965 CE04W1H3R3MT(RE3)
C622 00D 254 4573 981 CE04W1H100MT(RE3)
C623 00D 254 4569 924 CE04W1E101MT(RE3)
C624 00D 254 4569 911 CE04W1E470MT(RE3)
C625 00D 254 4573 949 CE04W1H010MT(RE3)
C626,627 00D 254 4569 937 CE04W1E221MT(RE3)
C628,629 00D 254 4573 981 CE04W1H100MT(RE3)
C630,631 00D 254 6258 000 CE68W1V822M
C632 00D 254 4573 949 CE04W1H010MT(RE3)
C633 00D 254 4761 719 CE04W1C223MC(SMQ)
C634 00D 255 1279 951 CQ93M1H104JT(B)
C635 00D 254 4569 911 CE04W1E470MT(RE3)
C636 00D 254 4573 965 CE04W1H3R3MT(RE3)
C637 00D 254 4573 949 CE04W1H010MT(RE3)
C638 00D 254 4761 719 CE04W1C223MC(SMQ)
C639,640 00D 254 4428 706 CE04W1V222MC (SMG)
C641,642 00D 254 4573 949 CE04W1H010MT(RE3)
C643 00D 254 4573 907 CE04W1H0R1MT(RE3)
C647 00D 254 4573 949 CE04W1H010MT(RE3)
C648 nsp 00D 257 0509 929 CK73B1H102KT +1608
C649 00D 254 4569 924 CE04W1E101MT(RE3)
C650 00D 254 4761 722 CE04W1C822MC(SMQ)
C651 00D 254 4761 706 CE04W1C153MC(SMQ)
C701 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C702 00D 254 4573 981 CE04W1H100MT(RE3)
C703 nsp 00D 257 0516 954 CK73B1E104KT +1608
C704 00D 254 4533 947 CE04W0J331MT SMG/RE3
C705 nsp 00D 257 0516 954 CK73B1E104KT +1608
Ref. No. nsp Part No. Part Name Remarks Q'ty New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-4306 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	102 dB
Dynamic power per channel (4 Ohm)	220 W
Dynamic power per channel (8 Ohm)	150 W
Power output per channel (1KHz@6 Ohm)	170 W
Power output per channel (20-20KHz@8 Ohm)	130 W
HDMI in	3
Line-in	Yes
Composite video in	7
USB ports quantity	1
Digital audio coaxial in	2
Digital audio optical in	5
Headphone connectivity	3.5 mm
Speakers connectivity type	RCA
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	1 W
Power consumption (typical)	570 W
3D	-
Optical drive included	No
Product color	Silver
Audio decoders	DTS 96/24, DTS Neo:6, DTS-ES, Dolby Digital, Dolby Digital EX, Dolby Pro Logic IIx
Apple docking compatibility	iPod

Weight and Dimensions

Depth	429 mm
Width	434 mm
Height	171 mm
Weight	18500 g
