Denon AVR-4311 User Manual

56
ENGLISH
Connect
Multi-channel + 2-channel with
Bi-Amp connection
You can connect the other front speakers for
2-channel playback using DIRECT mode or STEREO
mode via the bi-amp connection.
The speakers used exclusively for multichannel
playback and the speakers exclusively used for
2-channel playback are automatically switched for
playback in accordance with the surround mode.
To set the speakers for automatic switching during
playback via the bi-amp connection, select “Amp
Assign” and set “Assign Mode” to “2CH Bi-AMP”
using steps 3 and 4 of “Set up “Amp Assign””
(vpage59).
z Bi-Amp connection
FR
FR’
FL’
FL
C
SBL SBR
SL
SR
SW
Multi channel playback
(Surround mode)
2-channel playback
(Direct/Stereo mode)
Switching
For speaker impedance and speaker cable connections, see page 5.
FR’
FL’
wq
wq
1.AVR4311E2_ENG_6th_0810.indd 56 2010/08/12 10:12:01

Denon AVR-4311 Specifications

General

Type	AV Receiver
Number of channels	9.2
Output Power per Channel	140 W (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Total Harmonic Distortion	0.05%
Input Sensitivity/Impedance	200 mV / 47 kohms
Signal-to-Noise Ratio	102 dB
HDMI outputs	2
3D Support	Yes
Network features	AirPlay, DLNA
Audio DAC	24-bit/192kHz
Video Inputs/Outputs	Component
Audio Inputs/Outputs	Analog, Optical, Coaxial
Network Connectivity	Ethernet
Supported Audio Formats	Dolby TrueHD, DTS-HD Master Audio, FLAC, WAV, MP3, WMA, AAC
Dimensions (W x H x D)	434 x 195 x 427 mm
HDMI inputs	7 (1 on front)
