Making Detailed Settings (Manual Setup)
Main remote control unit
operation buttons
:Displaying the menu
Cancel the menu
:Moves the cursor
(Up/Down/Left/Right)
:Confirm the setting :Return to previous menu
Setting items Setting contents
Bass
Adjust low frequency range
(bass).
–10dB ~ +10dB (0dB)
Treble
Adjust high frequency range
(treble).
–10dB ~ +10dB (0dB)
HPF
Make settings for cutting
the low range to reduce
distortion in the bass.
OFF : The low range is not attenuated.
ON : The low range is attenuated.
Lch Level
Adjust the left channel
output level.
–12dB ~ +12dB (0dB)
The “Lch Level” can be set when “Channel“ (vpage 51) is set to
“Stereo“.
Rch Level
Adjust the right channel
output level.
–12dB ~ +12dB (0dB)
The “Rch Level” can be set when “Channel“ (vpage 51) is set to
“Stereo“.
Channel
Set the signal output from
multi-zone.
Stereo : Select stereo output.
Mono : Select mono output.
When “Amp Assign” - “Assign Mode” (vpage 40) is set to “FREE”,
and the signal assigned to the power amp is set to “Z2/Z3(M)”, the
“Channel” setting automatically becomes “Mono”.
Volume Display
Set how volume is
displayed.
Relative : Display - - - dB (Min), in the range –80 dB ~ 18 dB.
Absolute : Display in the range 0 (Min) ~ 99.
The “Volume Display” setting is applied also to the “Volume Level”,
“Volume Limit” and “Power On Level” display method.
The “Volume Display” setting applies to all zones.
•
•
Set the audio to playback with multi-zone (ZONE2, ZONE3).
Making the Multi-zone Settings (Zone Setup)
Default settings are underlined.
Setting items Setting contents
Volume Level
Set the volume output level.
Variable : Volume adjustment enabled by main unit and remote control
unit.
–40dB (41) : Fix volume at –40 dB. Set when adjusting volume by external
amplifier.
0dB (81) : Fix volume at 0 dB. Set when adjusting volume by external
amplifier.
When “Amp Assign” – “Assign Mode” (vpage 40) is set to “+Z2”,
“+Z2+Z3”, “ALL Z2” or “ALL Z2+Z3”, the “Volume Level” setting is
automatically set to “Variable”.
Volume Limit
Make a setting for maximum
volume.
OFF : Do not set a maximum volume.
–20dB (61) / –10dB (71) / 0dB (81)
Can be set when the multi-zone “Volume Level” setting (vpage 51)
is “Variable”.
Power On Level
Define the volume setting
that is active when the
power is turned on.
Last : Use the memorized setting from the last session.
– – – (0) : Always use the muting on condition when power is turned on.
–80dB ~ 18dB (1 ~ 99) : The volume is adjusted to the set level.
Can be set when the multi-zone “Volume Level” setting (vpage 51)
is “Variable”.
Mute Level
Set the amount of attenuation
when muting is on.
Full : The sound is muted entirely.
–40dB : The sound is attenuated by 40 dB down.
–20dB : The sound is attenuated by 20 dB down.
