ENGLISH
[Input source]
DVD/HDP TV/CBL VCR V.AUX
[Selectable items]
ON
: Enable conversion.
OFF
: Disable conversion.
A1 ~ A4 Video Convert
Automatically convert video input signal to monitor output
format.
[Display]
1 . S p 2 . I n 3 . O p
W
I n p u t S e t u p
W
1 1 D V D : C o n v O N
A5 Audio Delay
Compensate for mismatched timing between video and audio.
[Display]
1 . S p 2 . I n 3 . O p
W
I n p u t S e t u p
W
1 5 A . D e l a y 0 m s
This cannot be adjusted when playing in the EXT. IN, DIRECT or
STEREO mode (with “Front Speaker” set to “Large”, “Tone Defeat” to
“ON” and “Room EQ” to “OFF”).
Delay audio.
This sets the delay time for audio signals.
[Variable range]
0 ms
~
200 ms
With a movie source, for example, adjust so that the movement of the
actors’ lips is synchronized with the sound.
Input terminals
Component
video1
Component
video2
Component
video3
Default setting DVD/HDP TV/CBL VCR
[Input terminals]
Component video1 Component video2
Component video3
[Assignable input sources]
DVD/HDP TV/CBL VCR V.AUX
k ~ A0 Component In Assign
Select component video input to assign to this source.
[Display]
1 . S p 2 . I n 3 . O p
W
I n p u t S e t u p
W
8 C O M P 1 D V D
[Assignable input sources]
CD AUX CDR DVD/HDP TV/CBL VCR V.AUX
With the default settings, the Control Dock for iPod can be used
connected to the VCR (iPod) connector.
j iPod Assign
Assign Control Dock for iPod to this source.
[Display]
1 . S p 2 . I n 3 . O p
W
I n p u t S e t u p
W
7 i P o d V C R
A6 EXT. IN Subwoofer Level
Set the subwoofer level for playback.
Select according to the player in use.
[Display]
1 . S p 2 . I n 3 . O p
W
I n p u t S e t u p
W
1 6 E X T . I n S W + 1 5
[Selectable items]
0dB +5dB +10dB
:
Select according to the player in use.
+15dB
:
This is the recommended level.
Operations (vpage 22)
Setup
