Denon AVR-688


Getting Started Connections Setup Playback Remote Control Multi-Zone Information Troubleshooting
ENGLISH
iQ0Q2 oQ1Q3
Q4Q5
uq r t yw e
Rear Panel

Getting Started Connections Setup Playback Remote Control Multi-Zone Information Troubleshooting
q Digital audio connectors
(OPTICAL / COAXIAL) ························ (11 ~ 13)
w Analog audio connectors (AUDIO) ·············(11)
e EXT. IN connectors ····································· (15)
r REMOTE CONTROL jack ···························· (17)
t PRE OUT connector ······································ (9)
y ZONE2 connectors······································ (17)
u AC OUTLETS ··············································· (17)
i Power cord ·················································· (17)
o Speaker terminals (SPEAKERS) ············ (9, 47)
Q0 FM/AM antenna terminals
(TUNER ANTENNA) ···································· (16)
Q1 COMPONENT VIDEO connectors ···············(11)
Q2 HDMI connectors ········································ (10)
Q3 VIDEO / S-VIDEO connectors ·····················(11)
Q4 XM connector (SAT TU) ······························ (15)
Q5 DOCK CONTROL jack ································· (12)
