Denon AVR-688

q Bornes audio numériques
(OPTICAL / COAXIAL) ························ (11 ~ 13)
w Bornes audio analogiques (AUDIO) ···········(11)
e Bornes EXT. IN ············································ (15)
r Prises REMOTE CONTROL ························· (17)
t Borne PRE OUT ············································· (9)
y Bornes ZONE2 ············································· (17)
u Sorties CA (AC OUTLETS) ························· (17)
i Cordon d’alimentation ······························· (17)
o Bornes d’enceintes (SPEAKERS) ··········· (9, 47)
Q0 Bornes d’antennes FM/AM
(TUNER ANTENNA) ···································· (16)
Q1 Bornes COMPONENT VIDEO ······················(11)
Q2 Bornes HDMI ··············································· (10)
Q3 Bornes VIDEO / S-VIDEO ····························(11)
Q4 Borne XM (SAT TU) ····································· (15)
Q5 Prise DOCK CONTROL ································ (12)
Panneau arrière
Introduction
iQ0Q2 oQ1Q3
Q4Q5
uq r t yw e

