Denon AVR-X2100W Service Manual

+20dB
+10dB
0dB
-20dB
-30dB
-40dB
-10dB
+20dB
+10dB
0dB
-20dB
-30dB
-40dB
-10dB
0dBFS
1.41Vrms
AVR-S900/X2100W
LEVEL DIAGRAM
SURR.BACK ch
0dBFS
-10dBFS
-20dBFS
-30dBFS
-40dBFS
-29dBFS(A/D IN)
200mV
+30dB
SP OUT
4.48Vrms/8Ω
+
26dB
-
2+3+6=+7dB
N
ON CLICP MAX SIGNAL LEVEL 4.0Vrms
Config2 DOLBY LIMIT LEVEL 1.41Vrms(ALLch-3dBFS)
+3dB
-26dBFS(DIG.IN)
DD EX Config1
-
2+3=1dB
DOLBY LIMIT LEVEL 1.41Vrms(ALLch-3dBFS)
SP OUT(D/A OUT)
-32.5dBFS(DIG.IN)
DD EX Config2
INPUT : -23dBFS(DIG.IN) D.D
-2+6.5+3=7.5dB
INPUT : 200mV(A/D IN)
Mch STEREO
＋
＋
SPEAKER
DSP
R2A15218FP
GAIN
PCM1690
D/A
－
－
＋
PLD
102

Denon AVR-X2100W Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	150 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	8
Composite video in	2
Component video (YPbPr/YCbCr) in	1
Speakers connectivity type	-
Ethernet LAN	Yes
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Optical drive included	No
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIx, Dolby TrueHD, DTS 96/24, DTS-ES, DTS-HD
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	167 mm
Weight	9700 g
