Denon AVR-X2100W Service Manual

DISASSEMBLY
• Remove each part in the order of the arrows below.
• Reassemble removed parts in the reverse order.
• Read
"Precautions During Work"
before reassembling removed parts.
• If wire bundles are removed or moved during adjustment or part replacement, reshape the wires after completing the
work. Failure to shape the wires correctly may cause problems such as noise.
FRONT PANEL ASSY
See "DISASSEMBLY"
1. FRONT PANEL ASSY
and "EXPLODED VIEW"
FRONT HDMI PCB
(Ref. No. of EXPLODED VIEW : P1)
FRONT PCB
(Ref. No. of EXPLODED VIEW : P3)
FUNCTION PCB
(Ref. No. of EXPLODED VIEW : P4)
CNT PCB
(Ref. No. of EXPLODED VIEW : P5)
F/H_GUIDE PCB
(Ref. No. of EXPLODED VIEW : P6)
BLUETOOTH PCB
(Ref. No. of EXPLODED VIEW : P16)
TOP COVER
MAIN TRANS
See "DISASSEMBLY"
7. MAIN TRANS
and "EXPLODED VIEW"
MAIN TRANS
(Ref. No. of EXPLODED VIEW : 13)
RADIATOR ASSY
See "DISASSEMBLY"
2. RADIATOR ASSY
and "EXPLODED VIEW"
AMP PCB
(Ref. No. of EXPLODED VIEW : P7)
GUIDE L PCB
(Ref. No. of EXPLODED VIEW : P17)
TOP_GUIDE PCB
(Ref. No. of EXPLODED VIEW : P18)
GUIDE R PCB
(Ref. No. of EXPLODED VIEW : P19)
HDMI PCB ASSY
See "DISASSEMBLY"
3. HDMI PCB ASSY
and "EXPLODED VIEW"
HDMI PCB
(Ref. No. of EXPLODED VIEW : P13)
CX870 MIDDLE PCB
(Ref. No. of EXPLODED VIEW : P20)
CX870 MODULE
(Ref. No. of EXPLODED VIEW : P21)
RS232C PCB
(Ref. No. of EXPLODED VIEW : P14)
RS CNT PCB
(Ref. No. of EXPLODED VIEW : P15)
VIDEO PCB ASSY
See "DISASSEMBLY"
4. VIDEO PCB ASSY
and "EXPLODED VIEW"
VIDEO PCB
(Ref. No. of EXPLODED VIEW : P12)
MAIN PCB ASSY
See "DISASSEMBLY"
5. MAIN PCB ASSY
and "EXPLODED VIEW"
MAIN PCB
(Ref. No. of EXPLODED VIEW : P12)
FRONT CNT PCB
(Ref. No. of EXPLODED VIEW : P11)
INPUT PCB
(Ref. No. of EXPLODED VIEW : P10)
SMPS PCB
See "DISASSEMBLY"
6. SMPS PCB
and "EXPLODED VIEW"
SMPS PCB
(Ref. No. of EXPLODED VIEW : P8)
12

Denon AVR-X2100W Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	150 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	8
Composite video in	2
Component video (YPbPr/YCbCr) in	1
Speakers connectivity type	-
Ethernet LAN	Yes
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Optical drive included	No
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIx, Dolby TrueHD, DTS 96/24, DTS-ES, DTS-HD
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	167 mm
Weight	9700 g
