Denon AVR-X2100W Service Manual

5. Protection Pass Mode
5.1. Actions
• This mode allows the power to be turned on without activating protections.
• This is the same as normal power-on, except that protections are not activated.
5.2. Operations
AVR-X2100W
· Hold down buttons "
TUNER PRESET CH +
", "
ZONE2 SOURCE
" and "
STATUS
" at the same time and press the power
button to turn on the power.
AVR-S900W
· Hold down buttons "
ZONE2 SOURCE
", "
TUNER PRESET CH +
" and "
TUNE +
" at the same time and press the power
button to turn on the power.
The device returns to the normal display after the following is displayed.
FLD
P r o t e c t i o n P a s s
This is displayed for 5 seconds before returning to the normal display.
6. CX870 / CY920 Reboot mode
6.1. Actions
• The CX870 / CY920 is restarted after CX870 / CY920 hangup.
• The CX870 / CY920 can be restarted even in the network standby setting ("
Setup menu
" – "
Network
" – "
Network
" –
"
Always On
").
6.2. Operations
1. Turn on the button "
MAIN ZONE
" and set NETWORK as the input source.
2. Hold down buttons "
TUNER PRESET CH +
" and "
TUNER PRESET CH -
" for at least 3 seconds while the power is on.
3. FL display during CX870 / CY920 reboot
FLD
N e t w o r k R e s t a r t
4. Returns to the normal display.
NOTE:
• The CX870 / CY920 Reboot operation is not accepted again for one minute after executing the reboot.
• Reception is prohibited during update, save and load.
55

Denon AVR-X2100W Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	150 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	8
Composite video in	2
Component video (YPbPr/YCbCr) in	1
Speakers connectivity type	-
Ethernet LAN	Yes
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Optical drive included	No
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIx, Dolby TrueHD, DTS 96/24, DTS-ES, DTS-HD
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	167 mm
Weight	9700 g
