Denon AVR-X2100W Service Manual

1. Version Display Mode
1.1. Actions
Version information is displayed when the device is started in this mode.
1.2. Starting up
Hold down buttons "
DIMMER
" and "
STATUS
" at the same time and press the power button to turn on the power.
Press the "
STATUS
" button after this to show the information in section 1.3 on the display.
b
A version list is also displayed on GUIs while the version appears on the display.
1.3. Display Order
Error information(See "
1.4. Error display
") →
q
Model destination information →
w
Firmware Package Version
→
e
Main µ-com →
r
Main 1st Boot Loader →
t
DSP ROM →
y
Audio PLD →
u
Video PLD →
i
GUI SFLASH
→
o
Ethernet 1st Boot Loader, Hardware ID →
Q0
Ethernet 2nd Boot Loader, Rhapsody Flag
→
Q1
Ethernet IMAGE →
Q2
Ethernet MAC ADDRESS information →
Q3
BT MAC Address information
q
Model destination information :
FLD
A V R - S 9 0 0 W E 3 *
FLD
A V R - X 2 1 0 0 W E 3 *
FLD
A V R - X 2 1 0 0 W E 2 *
FLD
A V R - X 2 1 0 0 W E 1 *
FLD
A V R - X 2 1 0 0 W E 1 C *
FLD
A V R - X 2 1 0 0 W J P *
w
Firmware Package Version :
FLD
P a c k a g e : * * * *
e
Main µ-com Version :
FLD
M a i n : * * * * # # # # *
*
：
Main version,
#
：
Sub version
r
Main 1st Boot Loader :
FLD
M a i n F B L : * * . * *
t
DSP ROM :
FLD
D S P : * * . * *
y
Audio PLD :
FLD
A u d i o P L D : * * . * *
u
Video PLD
FLD
V i d e o P L D : * * . * *
i
GUI SFLASH :
FLD
G U I : @ @ $ \ * * * *
@
：
Model code,
$
：
Brand code,
\
：
Region code,
*
：
version
21

Denon AVR-X2100W Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	150 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	8
Composite video in	2
Component video (YPbPr/YCbCr) in	1
Speakers connectivity type	-
Ethernet LAN	Yes
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Optical drive included	No
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIx, Dolby TrueHD, DTS 96/24, DTS-ES, DTS-HD
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	167 mm
Weight	9700 g
