Denon AVR-X2100W Service Manual

4. Remote ID Setup Mode
4.1. Actions
This function allows only the desired AV receiver to be operated if multiple DENON AV receivers are used in the same
room.
4.2. Starting up
AVR-X2100W
·Hold down buttons "
ZONE2 SOURCE
", "
DIMMER
" and "
STATUS
" at the same time and press the power button to turn on
the power.
AVR-S900W
·Hold down buttons "
TUNER PRESET CH+
", "
TUNE -
" and "
TUNE +
" at the same time and press the power button to turn
on the power.
Select the "
6. REMOTE ID
" using the button "
TUNER PRESET CH+ / -
", and press the button "
STATUS
" to commit the
selection.
4.3. Operations
(1) When Remote ID Setup mode is started, the following is displayed.
FLD
R E M O T E I D ?
(2) Press the "
QUICK SELECT 1 - 4
" button that corresponds to the number you want to set.
Button Display
QUICK SELECT 1
R E M O T E I D 1
QUICK SELECT 2
R E M O T E I D 2
QUICK SELECT 3
R E M O T E I D 3
QUICK SELECT 4
R E M O T E I D 4
(3) Press the power button to turn off the power.
(4) Press the power button to turn on the power.
b
Only "
QUICK SELECT 1 - 4
" and the POWER button on the unit can be used in Remote ID Setup Mode.
s
4.4. Setting the Remote coutrol unit
s
(1) Pressandhold"
DEVICE MENU
"buttonforatleast3seconds"
DEV.
","
TU
"and"
AVR
"indicatorsashtime.
(2) Pressthe"
MAIN
"button.
The"
DEV.
","
TU
"and"
AVR
"indicatorsashtwice.
(3) Pressthe"
1
","
2
","
3
"or"
4
"button.
The"
DEV.
","
TU
"and"
AVR
"indicatorsashtwice.
NOTE:
If the ID of the unit and remote control do not match, "
AVAMP
z
" appears on the display of the unit when the remote
control is used (*: own remote control ID).
54

Denon AVR-X2100W Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	150 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	8
Composite video in	2
Component video (YPbPr/YCbCr) in	1
Speakers connectivity type	-
Ethernet LAN	Yes
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Optical drive included	No
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIx, Dolby TrueHD, DTS 96/24, DTS-ES, DTS-HD
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	167 mm
Weight	9700 g
