Denon AVR-X2100W Service Manual

YES
YES
YES
NO
NO
NO
NO
NO
NO
YES
YES
No picture or sound is output.
Check the Blu-ray/DVD player.
Check the connection of the HDMI/DVI cable.
(1) Is the HDMI/DVI cable correctly inserted?
(3) Is a certied HDMI cable (with the HDMI mark) being used?
(4) Is the HDMI/DVI cable shorter than 5m?
(5) Are a picture and sound output when a different HDMI/DVI cable is
used?
(2) Is an HDMI/DVI selector, repeater or image quality improvement
device being used?
(6) Are the HDMI output settings of the Blu-ray/DVD player correct?
(8) Are a picture and sound output
when the resolution of the Blu-
ray/DVD player is changed?
(10) Are a picture and sound
output when a different Blu-
ray/DVD player is used?
(7) If using a DENON Blu-ray/DVD player, is the "HDMI" indicator of
the uorescent display lit?
Proceed to YES if using a Blu-ray/DVD player from another com-
pany.
(9) Is sound output from the speaker terminal of this unit when the
power of the TV is turned off or the cable connecting the TV to this
unit is removed?
Check the connection of the HDMI/DVI cable.
Use a certied HDMI cable (with the HDMI mark).
Replace the HDMI/DVI cable with one shorter than 5m
(2m is recommended) and check again.
The HDMI/DVI cable is faulty.
Remove all of these and connect only the HDMI/DVI
cable.
Check the instruction manual of the Blu-ray/DVD player
and set the HDMI output correctly.
Set the output resolution of the Blu-ray/DVD player to a
resolution supported by the TV.
The Blu-ray/DVD player is faulty.
The Blu-ray/DVD player may not support the HDCP
repeater function.
Check with the manufacturer of the Blu-ray/DVD player.
NO
NO
NO
YES
NO
YES
YES
YES
YES
3. HDMI/DVI
3.1. No picture or sound is output (HDMI to HDMI)
85

Denon AVR-X2100W Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	150 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	8
Composite video in	2
Component video (YPbPr/YCbCr) in	1
Speakers connectivity type	-
Ethernet LAN	Yes
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Optical drive included	No
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIx, Dolby TrueHD, DTS 96/24, DTS-ES, DTS-HD
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	167 mm
Weight	9700 g
