Denon AVR-X2100W Service Manual

EXPLODED VIEW
TOP COVER
1차 부착
2차 부착
23
J X3
J X3
K X3
AVR-X2100BKE3/BKE2
J X2
(INLET)
(SCREW : 1500-04008-3B1-0S)
L
K
1
2
4
6
7
8
9
5
10
P1
P2
P3
P4
P5
P6
11
6
AVR-X2100SPE1C
12
13
15 X4
16 X4
14X2
17
18
19
20
21 X5
P7
B x4
A x6
A X2
A x2
G x4
A
H X21
A
A X5
D x6
A
M X2
A
I X2
A
P17
P18
A
26
27 X3
27
28
HDMI JACK/TUNER PACK/M3 BRACKET
30
31
A X26
(FRONT PCB&FUNCTION PCB
H/P PCB&USB PCB&FRONT HDMI PCB&SUB PANEL+FRONT PANEL)
22
P8
D
A
P13
P12
P9
A X2
P10
P14
P11
P15
A X6
29 X2
[SAME AS AVR13SERIES]
33
25X2
34
3
AVR X2100BKE3
28
AVR X2100BKE3
1
AVR-X2100BKE3/E2/E1/K
35
36
9
6
24
32
34
1
37
17
17
38
39
41-1
40
38
39
41-2
40
A
P17
P20
P21
28
A X2
P16
CX1
EX3
F x2
42
A1
B1
C1
A5
B5
C5
A6
B6
C6
A7
B7
C7
A2
B2
C2
A3
B3
C3
A4
B4
C4
WARNING:
Parts marked with this symbol
z
have critical characteristics.
Use ONLY replacement parts recommended by the manufacturer.
Please see the last chapter for the part list.
143

Denon AVR-X2100W Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	150 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	8
Composite video in	2
Component video (YPbPr/YCbCr) in	1
Speakers connectivity type	-
Ethernet LAN	Yes
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Optical drive included	No
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIx, Dolby TrueHD, DTS 96/24, DTS-ES, DTS-HD
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	167 mm
Weight	9700 g
